MarStand
Plate for Single Measurement
OVERVIEW
40 40 130
100 100 130
12
40
40 40
Product type 827 b 31 827 b 32 827 b 33
Order no. 4082731 4082732 4082733
Product features
• For single measurement • For compound measurement • For single measurement
• Hardened and lapped • Hardened and lapped • Hardened and lapped
• Reversible • With 8 mm mounting bore and • Reversible
• One measuring surface with clamping device for inductive probes • Large measuring surface with
longitudinal ribbing • Measuring sur face with longitudinal ribbing
• Both sides face lapped longitudinal ribbing • Both sides face lapped
ø7,5
70
130
130
12
40
Product type 827 b 34 827 b 35 827 b 36
Order no. 4082734 4082735 4082736
Product features • For compound measurement • Ensures that a workpiece is correctly • With adjustment screws for parallel
• Hardened and lapped positioned alignment of 2 plan surfaces
• With 8 mm mounting bore and • To be attached to plates 827 b 31 • Particularly suit able for mounting pin
clamping device for inductive probes and 827 b 32 gages 426 M
• Large measuring surface with • To be attached to plates 827 b 31
longitudinal ribbing and 827 b 32
