MarStand

Post and Support Assemblies

OVERVIEW

40-230 50-190
50-200
8 ø8
11 ø8
ø14 ø18
50-100 220 34 34
220 285 485
14 ø18 ø25
18
10 10 14
M10 M10 M16
Product type 815 XMA 815 XMB 815 XMS 285
Order no. 4424005 4424006 4435011
Product features
• Sturdy design with mounting thread • Sturdy design with mounting thread • Sturdy design with mounting thread
• Two joints • One joint • One joint
• Post and support arm are made of • Post and support arm are made of • Post and support arm are made of
stainless steel stainless steel stainless steel
• With fine adjustment • With fine adjustment • With fine adjustment

40-230 34
50-200 ø8 ø8
ø8 ø11
ø11
ø18
50-100 245 40-130
34 175
285 485 ø14 ø14
ø25 ø18

4,5
14 6 5,5
10,5
M16 17 M8 x 0,75
Product type 815 XMS 485 815 XN 815 XP
Order no. 4435015 4424000 4424015
Product features • Exceptionally sturdy design with • Sturdy design for mounting in a • Sturdy design with mounting thread
screw-in thread T-slot • One joint
• One joint • Two joints • Post and support arm are made of
• Stainless steel column and cantilever • Knurled nut for clamping stainless steel
arms • Post and support arm are made of • With fine adjustment
• Precision adjuster stainless steel
• With fine adjustment

MarStand | Indicator Stands, Comparator Stands, Run-Out Testing Instruments 321
