MarCator

Dial Indicator

FEATURES

• Unit construction and removable E
movement save repair/cleaning 19.1
.75
time and maintenance 6.4 AGD 6.4
.25
.25
• Hardened gears and stainless AGD AGD
steel racks provide lasting C A
protection against indicator AGD
failure due to shock or wear
• Jeweled bearings resist friction, 12.7
.50 *
add to longer indicator life
• Skeletonized, hobbed gears for B
more sensitive response, superior AGD D .375" or 8 mm
AGD
indicator accuracy with minimal
hysteresis error #4-48 Thr'd
• Soft tinted dials (green - inch / Range 6.4 AGD
.25
yellow - metric) minimize eye AGD AGD
strain
• Special steel alloy
• Balanced dial hand affords no
shift, precise reading TECHNICAL DATA
• Controlled rack and pinion mesh
eliminates slope for precise Order no. Product Measu- Graduation Type of Rev. Range Error limit Standard ANSI/AGD Dial
response and reading type ring span value dial face counter per rev. Group color
• Smooth adjusting bezels for easy inch inch inch inch
setup 2011157 C1/2K .010” .00005” 0– 2– 0 .004” ±.0001” ANSI 2 Green
• Positive pressure pull back spring 2011158 C1/2K-RC .010” .00005” 0– 4 • .004” ±.0001” ANSI 2 Green
requires less maintenance 2011161 C1K .020” .0001’’ 0– 4– 0 .008” ±.0001” ANSI 2 Green
• Compliance with ANSI/AGD 2011162 C1K-RC .020” .0001’’ 0– 8 • .008” ±.0001” ANSI 2 Green
dimensional and accuracy
specifications 2015781 22I .025” .0001’’ 0– 5– 0 .010” ±.0001” ANSI 2 Green
• These indicators are normally 2014761 22IN-RC .025” .0001’’ 0– 10 • .010” ±.0001” ANSI 2 Green
furnished with continuous dial 2015782 22QN .025” .00025” 0– 5– 0 .010” ±.00025” ANSI 2 Green
(with R.C.) or + on right balance 2014791 22QN-RC .025” .00025” 0– 10 • .010” ±.00025” ANSI 2 Green
dial (w/o R.C.), lug back and 2015783 23K .050” .00025” 0– 10– 0 .020” ±.00025” ANSI 2 Green
.18” by .250” long contact 2014808 23K-RC .050” .00025” 0– 20 • .020” ±.00025” ANSI 2 Green
• Optional dials: balanced dial with 2015784 23Q .050” .0005” 0– 10– 0 .020” ±.0005” ANSI 2 Green
+ on left; continuous clockwise;
continuous counterclockwise. 2014810 23Q-RC .050” .0005” 0– 20 • .020” ±.0005” ANSI 2 Green
(Order by part number and 2015786 25M .075” .0005” 0– 15– 0 .030” ±.0005” ANSI 2 Green
specify dial style desired) 2014811 25M-RC .075” .0005” 0– 30 • .030” ±.0005” ANSI 2 Green
• For other dial styles or special 2015787 26K .100” .0005” 0– 20– 0 .040” ±.0005” ANSI 2 Green
requirements - call Mahr 2014812 26K-RC .100” .0005” 0– 40 • .040” ±.0005” ANSI 2 Green
2015790 27I .125” .0005” 0– 25– 0 .050” ±.0005” ANSI 2 Green
2014814 27I-RC .125” .0005” 0– 50 • .050” ±.0005” ANSI 2 Green
2015785 23W .050” .001” 0– 10– 0 .020” ±.001” ANSI 2 Green
2014809 23W-RC .050” .001” 0– 20 • .020” ±.001” ANSI 2 Green
2015789 26Q .100” .001” 0– 20– 0 .040” ±.001” ANSI 2 Green
2014813 26Q-RC .100” .001” 0– 40 • .040” ±.001” ANSI 2 Green
2015791 27O .125” .001” 0– 25– 0 .050” ±.001” ANSI 2 Green
2014815 27O-RC .125” .001” 0– 50 • .050” ±.001” ANSI 2 Green
2015792 28IN .250” .001” 0– 50– 0 .100” ±.001” ANSI 2 Green
2011049 28IN-RC .250” .001” 0– 100 • .100” ±.001” ANSI 2 Green

186 MarCator | Dial and Digital Indicators
