ENGINE SERIES

VAUXHALL/OPEL

Petrol Engine Tension Adjustment Wrench Set (Via Water Pump)

9AT1202

• The set includes 41mm and 46mm tension adjust wrench 2
• Suitable for Vauxhall / Opel and Chevrolet engine P D CHAIN PC.
g 695 SET 6 / 24

9AT1202 - A(46MM)
Petrol / 1.8 and 2.0 S.O.H.C
Astra F, Calibra, Frontera C18NZ, C20NE
Diesel / 1.6D and 1.7D
Astra, Cavalier, Vectra 16DA, 17D
MODEL:
9AT1202 - B(41MM)
Petrol / 1.2 / 1.4 / 1.6 S.O.H.C
Corsa B / C , Combo, Astra-F, Vectra-B CONTENTS :
C12NE, X12SZ, C14NZ, X14NZ, C14SE • A - tension adjustment wrench (46mm)
X14SZ, X16SZ, X16SZR, Z16SE • B - tension adjustment wrench (41mm)

VAUXHALL/OPEL

Diesel Engine Setting & Locking Set

9AT2008E
• The set includes auxiliary belt tensioner locking pin, camshaft setting tools, crankshaft pulley
holding tool, chain tensioner locking pin and crankshaft locking pin
• Suitable for 2.0 dCi chain drive engines of Renault, Nissan and Vauxhall / Opel
g 2376 1 / 5 8
D CHAIN
MODEL: Vivaro (07-08) PC.
ENGINE M9R
CODE: 780/782/784

CONTENTS :
• A&H – camshaft gear alignment tool
• B&C – camshaft setting plate
• D – crankshaft locking pin
• E – auxiliary belt tensioner locking pin
• F – crankshaft pulley holding tool
• G - chain tensioner locking pin

Diesel Engine Setting Tool (Belt Drive)

9AT2-A01

• The set includes flywheel locking pin, TDC timing pin and tensioner retaining tool
• Use for holding engine timing position when replacing timing belt
• Suitable for Fiat, Iveco, Renault, Citroen / Peugeot, Vauxhall / Opel D BELT

g 112 12 / 120
2.5D / 2.8D
MODEL: Arena (97-01)
Movano (98-03)
S8U CONTENTS :
ENGINE 770, 772 • A – TDC timing pin
CODE: S9W • B – flywheel locking pin (2pc)
700, 702 • C – tensioner retaining tool A B C

532
