UNIVERSAL UNIVERSAL

Belt Tensioner Lock Pin Set Dial Test Indicator

9AT3-B01 9AT3-F01

• Designed for retaining tensioner plunger in fixed • Use to measure and accurately find the piston TDC position
position while replacing timing belt • This tool has to use with TDC Indicator 9AT3-F02
• Suitable for common vehicle and engine • It can be used for mechanical circularity, flatness.....etc

g 17 SET 20 / 100 g 63 SET 1 / 100

9AT3-F01

9AT3-F02

CONTENTS :
• 0.79mm / .0310" • 1.51mm / .0594"
• 1.21mm / .0476" • 1.71mm / .0670"
• 1.41mm / .0560" • 1.92mm / .0760"

VOLKSWAGEN GROUP AUDI / SKODA / VW / SEAT

Petrol Engine Setting & Locking Set

9AT1506E P CHAIN 6

• The set includes dial & TDC indicator and camshaft setting tool PC.
• Suitable for 1.2T / 1.4T FSi and 1.4 / 1.6 FSi engines
• Use to check and adjust engine timing

g 1856 1 / 10

Audi
A1(10-12), A3(03-12)
Seat
Altea/Altea XL(08-12), Ibiza/Cordoba(08-12)
Leon(07-12), Toledo(07-09)
Skoda
Fabia II(07-12), Octavia II(04-12) Roomster(06-12),
MODEL:
Superb II(09-12)
Yeti(09-12) • CONTENTS :
VW • A – camshaft setting plate
Caddy/ Caddy Maxi(10-12), Eos(06-12) Golf(03- • B – TDC indicator
12), Golf Plus(03-12), Jetta(06-12) Passat(05-11), • C – camshaft setting tool
Polo(02-12), Scirocco(08-12) Tiguan(07-12), • D – crankshaft locking pin
• E – dial test indicator
Touran(03-12) • F – tensioner locking pin
1.2T FSi
CBZA, CBZB, CBZC
1.4T FSi
BLG, BMY, BWK, CAVA, CAVB, CAVC, CAVD
ENGINE CAVE, CAVF, CAXA, CAXC, CDGA, CSMA
CODE:
1.4 FSi
AXU, BKG, BLN
1.6 FSi
BAG, BLF, BLP, BTS
