ENGINE SERIES

VOLKSWAGEN GROUP AUDI/SKODA/VW/SEAT

Petrol Engine Twin Camshaft Setting & Locking

Set - VAG 1.4 / 1.6 FSi (Chain)

9AT1103E 3
P CHAIN PC.
• The set includes camshaft setting plate, TDC position
tool (with DTI) and tensioner locking pin
• 9AT1103 ´B´ TDC positioning tool has to use with
9AT3-F01(not included in this set)
g 1456 1 / 10
Audi
A3 (03-07)
Volkswagen
MODEL: Polo (02-08), Golf V (03-08), Golf Plus (05-08)
Jetta (06-08), Passat (05-08), Touran (03-07)
Skoda
Octavia II (04-08) CONTENTS :
1.4 FSI • A - camshaft setting plate
ENGINE AXU, BKG, BLN • B - TDC position tool (with DTI)
• C - tensioner locking pin
CODE: 1.6 FSI
BAG, BLF, BLP, BTS
VW/AUDI

VW Audi TIMING TOOL Set VAG 1.6/2.0 TDI CR

9AT2010E

• This set designs to fit the newest common rail diesel engine which is significantly different
from the older PD engine.
• The CR engines combines belt and the gear drive by using a toothed belt to transfer the
drive from the crankshaft to one of the cam shafts, then using gears to transfer the drive
from one cam to the other.
Kg 2.7 1 / 4
10
D CHAIN
Audi A3, A4, A5, A6, Q5 PC.
MODEL:
Volkswagen Golf, Tiguan, Passat, Eos

1.2 TDi
ANY, AYZ
1.4 TDi
AMF, ATL, BAY, BHC, BNM, BNV
1.9 TDi
AJM, AMG, ANJ, ARL, ARX, ASZ, ATD, ATJ,
AUY,AVB, AVF, AVQ, AWX, AXB, AXC, AXR,
ENGINE : BEW, BJB, BKC, BKE, BLS, BLT, BMT, BPX,
BRB, BRM, BRU, BSU, BSV, BSW, BTB, BVK,
BXE, BXF
2.0 TDi D
AZV, BKD, BDJ, BDK, BGW, BHW, BKP, BLB,
BMA, BMM, BMN, BMP, BMR, BNA, BPW, BRC, F E G
BRE, BRF, BRT, BSS, BUY, BUZ, BVE,BVF, BVG,
BVH, BVW I A

H C B H

CONTENTS:
• A - Injection pump/ camshaft alignment pin
• B - Crankshaft pulley locking tool(Bored)
• C - Crankshaft pulley locking tool(Non-bored)
• D - Tensioner pulley adjustment tool(2.4mm Hex Key)
• E - Tensioner pulley locking tool
• F - auxiliary tensioner locking tool(3.9mm)
• G - Sprocket holding tool
• H - Cam sprocket hub puller
• I - Oil Pump /Balancer Shaft Alignment Tool
