TORQUE CONTROL &
MULTIPLIERS
Heavy Duty Adjustable Torque Wrench

• Design for easy torque adjustment
• Quality accords to DIN ISO 6789:2017 & ASME B107.300-2010 10,000 3
• Tolerance of torque ± 3%(CW)
• CW/CCW Direction

GG Series kgf.m & N.m

3/8'' 34362

KT NO Square Torque range Incr. Torque range lncr Gear Overall length g DK
drive
kgf.m
mm
teeth
N.m
34362-1GG 3/8" 40~200 kgf.m 1 kgf.m 4.4~19.1 0.92 24 324 640 1/12 34362-1DK
1/2'' 34362

KT NO Square Torque range Incr. Torque range lncr Gear Overall length g DK
drive
mm
N.m
teeth
kgf.m
034462-1GG 1/2" 400~2000 kgf.m 10 kgf.m 44.1~191.2 N.m 0.46 N.m 32 521 1590 1/12 034462-1DK
034462-3DK:
034462-3GG 1/2" 200~1000 kgf.m 5 kgf.m 22.1~95.6 N.m 4.9 N.m 32 436 1470 1/12 34462-3DG/3GG
Heavy Duty Mini-type Torque Wrench

• Industrial application
• Quality accords to DIN ISO 6789:2017 & ASME B107.300-2010 10,000 3
• Tolerance of torque ±3%(CW)
• CW/CCW Direction

Quick release

Automatic quick return adjustment

MINI Series

1/4'' 3426C

KT NO Square Torque range lncr. Gear Overall length g DK
mm
teeth
N.m
drive
3426C-1DF 1/4" 3~15 N.m 0.1 N.m 64 211 330 1/24 3426C-1DK
3426C-2DF 1/4" 5~25 N.m 0.2 N.m 64 249 430 1/24 3426C-1DK

3/8'' 3436C

KT NO Square Torque range lncr. Gear Overall length g DK
drive
teeth
mm
N.m
3436C-1DF 3/8" 3~15 N.m 0.1 N.m 64 211 450 1/24 3436C-1DK
3436C-2DF 3/8" 5~25 N.m 0.2 N.m 64 249 550 1/24 3436C-1DK
286
