Page 268 - 蓝带金统立KINGTONY2025年样本
P. 268
Standard Impact Impact Accessory
Socket & Rail Set 2863P 1/4"
• Adapter
2535M 1/4" • Convert to 3/8" drive
• DIN 3129, ISO 2725-2 • DIN 3121 D
KT NO. Spec. D g
D1 D2 mm
2863P 1/4"F x 3/8"M 14 20 12 / 360
l L
Deep Impact Socket
3435M 3/8"
L
D1
D2
ℓ
KT NO. mm mm mm mm mm g
253504M 4 7.5 13 4 23 12 20 / 600 • DIN 3121
253545M 4.5 8.1 13 5 23 12 20 / 600 3435S 3/8"
253505M 5 8.8 13 6 23 11 20 / 600
253555M 5.5 9.4 13 6 23 12 20 / 600 • ANSI / ASME B107.2
253506M 6 10.0 13 7 23 13 20 / 600
253507M 7 11.3 13 7 23 13 20 / 600
253510M 10 15.0 13 9 23 17 12 / 360
253513M 13 18.8 13 9 23 22 12 / 360
253514M 14 19.8 13 9 23 23 10 / 300 D1 D2
Standard Impact Socket l L
3535M 3/8"
• DIN 3129, ISO 2725-2
D2
L
D1
ℓ
3535S 3/8" KT NO. mm mm mm mm mm g
• ANSI / ASME B107.2 343506M 6 10.6 19 10 65 50 6 / 120
343507M 7 11.8 19 10 65 55 6 / 120
343508M 8 13.2 19 12 65 68 6 / 120
D1 D2 343509M 9 14.5 19 12 65 65 6 / 120
343510M 10 15.5 19 12 65 82 6 / 120
l L 343511M 11 17.0 19 13 65 75 6 / 120
343512M 12 18.2 19 14 65 89 6 / 120
343513M 13 19.4 22 14 65 111 6 / 120
343514M 14 20.7 22 14 65 109 6 / 120
343515M 15 22.0 22 16 65 112 6 / 120
L
D2
D1
ℓ
KT NO. mm mm mm mm mm g 343516M 16 23.8 22 16 65 126 6 / 96
353506M 6 10.6 19 5 32 33 12 / 360 343517M 17 24.8 22 17 65 143 6 / 96
353507M 7 11.8 19 5 32 33 12 / 360 343518M 18 25.8 22 18 65 133 6 / 96
353508M 8 13.2 19 6 32 35 12 / 360 343519M 19 27.6 22 20 65 171 6 / 96
353509M 9 14.5 19 6 32 36 12 / 360 343520M 20 28.3 22 20 65 154 6 / 96
353510M 10 15.5 19 7 32 37 12 / 360
353511M 11 17.0 19 7 32 39 12 / 360 343521M 21 29.5 22 22 65 161 6 / 96
353512M 12 18.2 19 8 32 39 12 / 360 343522M 22 30.8 22 22 65 178 5 / 60
353513M 13 19.4 22 9 32 53 10 / 200 343523M 23 32.0 22 24 65 177 5 / 60
353514M 14 20.7 22 9 32 54 10 / 200
353515M 15 22.0 22 10 32 56 10 / 200 343524M 24 32.5 22 24 65 176 5 / 60
353516M 16 23.8 22 10 32 57 10 / 200
353517M 17 24.8 22 11 32 58 10 / 200
353518M 18 25.8 22 11 32 62 10 / 200 KT NO. D1 D2 ℓ L g
353519M 19 27.6 22 13 32 63 10 / 160 Inch mm mm mm mm
343508S 1/4 10.8 19 10 63.5 62 6 / 120
L
D1
D2
ℓ
KT NO. Inch mm mm mm mm g 343510S 5/16 13.0 19 12 63.5 71 6 / 120
343512S
15.3
3/8
6 / 120
82
63.5
19
12
353508S 1/4 10.8 19 5 32 32 12 / 360 343514S 7/16 17.0 19 13 63.5 84 6 / 120
353510S 5/16 13.0 19 6 32 36 12 / 360 343516S 1/2 18.2 19 14 63.5 113 6 / 120
353512S 3/8 15.3 19 7 32 38 12 / 360 343518S 9/16 20.7 22 14 65 114 6 / 120
353514S 7/16 17.0 19 7 32 38 12 / 360 343520S 5/8 23.8 22 16 65 126 6 / 96
353516S 1/2 18.2 19 9 32 53 12 / 360 343522S 11/16 24.5 22 17 65 138 6 / 96
353518S 9/16 20.7 22 9 32 53 10 / 200 343524S 3/4 27.0 22 20 65 154 6 / 96
353520S 5/8 23.8 22 10 32 57 10 / 200 343526S 13/16 29.5 22 22 65 156 6 / 96
353522S 11/16 24.5 22 11 32 60 10 / 200 343528S 7/8 30.8 22 22 65 172 5 / 60
353524S 3/4 27.0 22 11 32 61 10 / 160
