Specialty Tools Specialty Tools

Commercial vehicle – Chassis Commercial vehicle – Chassis

Silent Block 4937 Commercial vehicle pin wrench set

Made in Germany
4937 Tool set for silent blocks • For repair and maintenance work on the wheel hub, wheel C 9
bearing or brake disc on MAN, MERCEDES-BENZ
• Significant time-saving, as no axle parts need to be removed C
G • Application: Slotted silent blocks can be safely pressed in and out • For e.g. MAN TGL front axle model years 2000→ and L 2000
MERCEDES-BENZ Atego rear axle HL 2
• MERCEDES-BENZ Actros 1, 2, 3 model year 2002 → – Stabiliser bearings
• Precise pin geometry for ideal tool operation in slotted nuts
• x 70 mm: MAN TGA,TGS, TGX – Shock absorber bearings • Precise fit
• x 68 mm: MAN (front spring) ROR, SAF – Shock absorber bearings • Solid design: high (shape) stability even with very
• x 66 mm: IVECO Eurostar – Cab high loosening or tightening torques
• x 65 mm: MERCEDES-BENZ Actros 1 ∙ Atego 1 ∙ • Pin wrench for rear axle, inside x: 87 mm
Axor 1, 2, 3 ∙ Econic 1 – Stabiliser bearings • Length (total): 65 mm
• x 63 mm: DAF • 6 pins, width of pins: 10 mm
• x 60°mm: MAN TAG, TGS, TGX – Leaf spring bearing VA, HA ∙ • Two replaceable guide tubes
MERCEDES-BENZ Actros, Axor – Leaf spring lug ∙ IVECO Eurostar – Leaf
F • x 58 mm: MERCEDES-BENZ 3229 B, 652, 650 ∙ Volvo Outside-x: 49 mm ∙ 57 mm
Length (total): 140 mm
spring lug ∙ RENAULT Kerax, Magnum, Premium – Leaf spring lug
• x 56 mm: IVECO Eurostar – Cab Operating tools for commercial
• Pulling in the slotted silent block using the spindle vehicle axle nuts and wheel hubs
• Optional use of hydraulic cylinder (e.g. HAZET 4932-17) possible • Surface: burnished
• Centring the bush during installation ensures safe operations,
no more canting possible when pressing in
• One-man operation
D

R

1 è 4
4937-2/32 32 222957 1 N è 4
4937-87/3 54 3 199235
Cardan Shafts
C • For repair and maintenance work on the rear axle C 9
Made in Germany
4685-1 Taper key extractor MERCEDES-BENZ

Made in Germany • For MERCEDES-BENZ Actros ∙
• Application: Safe removal of taper keys from the sprockets of agricultural Hypoid rear axle HL ∙ HL 8
machinery as well as manual operation of input shafts on accessory equipment • Precise fit
• Precise pin geometry for ideal
tool operation in slotted nuts
• Solid design: high (shape)
stability even with very high
O • Inside x: 117 mm
loosening or tightening torques
• Length (total): 200 mm
1 K 4 • 6 pins, pin width: 9.8 mm
• Guide tube
4685-1 420 222889 Outside x: 60 mm
length (total): 185 mm
• Surface: burnished
4685-2 Taper key extractor
A Made in Germany
• Application: Safe removal of taper keys from the
sprockets of agricultural machinery as well as manual
operation of input shafts on accessory equipment

U

1 K 4 1 N è 4
4685-2 366 222896 4937-117/2 180 2 199242
474 Valid until December 31, 2021 Components and spare parts from page 482 to 490
