Page 421 - HAZET英文2021

Specialty Tools Specialty Tools

Brakes Brakes

4956 Calliper gauge for brake discs 4956 Calliper gauge for brake discs

Made in Germany RK • Application: Simple, quick determination of the brake disc R
• Spherical measuring areas diameter through wheel opening with removing the wheels
• Measuring range 200 – 400 mm
• Application: Measuring the thickness of the brake discs • Universal application
G (wear/abrasion of the brake disc)
– follow the instructions of the manufacturer –
• Fixing screw and sliding vernier
(vernier /10)
1
• In leather case
• For passenger cars
and motorcycles
• Measuring range
up to 60 mm
• Jaw length 75 mm
F

1 4
D 4956-1 073160

Calliper gauge for brake
4956
discs / thickness gauge
• Measurement without wheel removal possible RK
• Effortless measurement on the vehicle as part of direct
receptions in the presence of the customer
R • Measuring range: 0 – 60 mm (also suitable for
application on commercial vehicles)
• Easy to handle
• Note: Information on the wear limits – Please observe vehicle manufacturer’s data

1 4

4956-4 222339
C 4968 Brake test tool set

• Micrometer screw for exact determination of the thickness of the brake R
disc
• Application: Checking the lateral run-out of the brake disc
• Precision dial gauge for checking the lateral run-out
• Hinged bracket with magnetic base as mounting and for an
exact positioning of the dial gauge on the vehicle
O • Plastic box
• Soft foam insert
1 K 4

4956-3 395 219032

A

U 2155 N-25 2155-60 2155-65

1 è 4
4968/3 3 149179
420 Valid until December 31, 2021 Components and spare parts from page 482 to 490
