Specialty Tools

Brakes

2191 Tube flaring tool set 2191 Tube deburring tool

Made in Germany R/ Made in Germany R
• For metal tubes and pipes with a wall thickness of 0.7 to 1.0 mm • For tubes with outside x of 4-32 mm
pipe x 4.75– 10 mm
• Application: For tube deburring
• Application: Making open (F) or twin (E) flares in accordance with DIN 74234,
standard 90° and 180° flares G
For flares on rolled and drawn pipes
• Replaceable, hinged gripping jaw
Note: For plastic-coated brake lines use HAZET 2193/4 K
• Special cast steel
• Sheet metal box (HAZET-blue)
• 2-component soft foam insert
1 t 4
F
2191-2 4 – 32 013814

2191 Base block
Made in Germany R
• For E, F, 90° and 180° flares
• 4.75 up to 10 mm
D

1 t 4
2191-3 4.75 – 10 013821

2191-1 2191 R
2181 N-1 2191-4 • 2191-5 2191 Thrust block
2191-6 • 2191-8
2191-9 • 2191-10 Made in Germany
2191-2 R
• For E and F-flares
• Surface: burnished, oiled
2191 2191-3 2191-90
1 L x W x H è 4 C
mm
2191/12 K 290 x 173 x 50 12 013890

2191 Basic unit

Made in Germany R
• Holding the gripping jaw 2191-1
1 t 4
2191- 4 4.75 013838 O
2191- 5 5 013845
2191- 6 6 013852
2191- 8 8 013869
2191- 9 9 013876
2191-10 10 013807

Made in Germany R
1 t 4 • For E and 90°, 180° flares
4.75 to 10 mm
2191 4.75 – 10 013784 • Surface: burnished, oiled A

2191 Gripping jaw
Made in Germany R
• Socket in basic unit 2191
• For E, F, 90° and 180° flares
• 4.75 up to 10 mm
U

1 mm 4 1 t mm 4
2191-1 4.75 – 5 – 6 – 8 – 9 – 10 mm 013791 2191-90 4.75 – 10 ( ⁄16″ – ⁄8″) 013883
3
3
Components and spare parts from page 482 to 490 Valid until December 31, 2021 417
