P. 296
Torque Technology
Insert tool holders
6414 Insert square drives 6430 Blank-end insert
Made in Germany C Made in Germany
• Surface: chrome-plated • Spring, bolt and cover included in delivery
• DIN 3120, ISO 1174-1 Caution: when welding-on tools, the release torque values may
change. Observe effective lengths (see conversion table on page 271)
1 Drive Output K N 1 2 5 4
1
6414 ( 14 x 18 i 12.5 = ⁄2″ 63.5 25 18 21.5 30 027668
6420 Insert tool holder for bits
Made in Germany
• Surface: chrome-plated 1 Drive K 1 2 5 4
• ISO 1173
6430 c ( 9 x 12 25 10 14.5 19 027958
6430 d ( 14 x 18 38 11 21.5 26 027965
6450 C Insert open-end wrench
Made in Germany
• Surface: chrome-plated
1 Drive Output K N 1 2 5 4
1
6420 b ( 9 x 12 h 6.3 = ⁄4″ 40.5 17.5 10 14.5 20 027903
6420 c ( 9 x 12 h 8 = ⁄16″ 41.5 17.5 12.5 14.5 20 027910
5
6420 d ( 14 x 18 h 8 = ⁄16″ 58 25 12.5 21.5 30 027927
5
1 5 4
6423 Insert adapter S Drive Output K N 1 2
6450 c- 7 7 ( 9 x 12 c 36.5 17.5 5.5 14.5 20 028429
Made in Germany 6450 c- 8 8 ( 9 x 12 c 37 17.5 5.5 14.5 21.5 028436
• Surface: chrome-plated 6450 c- 9 9 ( 9 x 12 c 37.5 17.5 5.5 14.5 23 028443
6450 c-10 10 ( 9 x 12 c 38 17.5 5.5 14.5 24.5 028320
6450 c-11 11 ( 9 x 12 c 38.5 17.5 5.5 14.5 26 028337
6450 c-12 12 ( 9 x 12 c 38.5 17.5 5.5 14.5 27.5 028344
6450 c-13 13 ( 9 x 12 c 39 17.5 5.5 14.5 29 028351
6450 c-14 14 ( 9 x 12 c 42 20 7.5 14.5 31 028368
6450 c-15 15 ( 9 x 12 c 42.5 20 7.5 14.5 33 028375
6450 c-16 16 ( 9 x 12 c 43 20 7.5 14.5 35 028382
6450 c-17 17 ( 9 x 12 c 43.5 20 7.5 14.5 37 028399
6450 c-18 18 ( 9 x 12 c 44 20 7.5 14.5 39 028405
6450 c-19 19 ( 9 x 12 c 45 20 7.5 14.5 41 028412
6450 d-13 13 ( 14 x 18 c 56.5 25 7 21.5 30 028450
6450 d-14 14 ( 14 x 18 c 57 25 7 21.5 32 028467
6450 d-15 15 ( 14 x 18 c 57.5 25 7 21.5 34 028474
6450 d-16 16 ( 14 x 18 c 58 25 9 21.5 35.5 028481
6450 d-17 17 ( 14 x 18 c 58.5 25 9 21.5 37 028498
6450 d-18 18 ( 14 x 18 c 59 25 9 21.5 39 028504
6450 d-19 19 ( 14 x 18 c 59.5 25 9 21.5 41 028511
6450 d-21 21 ( 14 x 18 c 60.5 25 11 21.5 45 028528
6450 d-22 22 ( 14 x 18 c 61 25 11 21.5 47 028535
6450 d-24 24 ( 14 x 18 c 62 25 11 21.5 51 028542
1 Drive Output K N 1 5 4 6450 d-27 27 ( 14 x 18 c 68.5 32.5 13 22.5 58.5 028559
70
028566
22.2 63
32.5 13
6450 d-30 30 ( 14 x 18
c
6450 d-32 32 ( 14 x 18 c 71.5 32.5 13 22.2 65 028573
• Square insert 14 x 18 to 9 x 12 6450 d-34 34 ( 14 x 18 c 73.2 32.5 13 22.2 68.5 050178
6423 c ( 9 x 12 ) 14 x 18 50 34 22.9 30 027934 6450 d-36 36 ( 14 x 18 c 70 32.5 13 22.2 67 072507
• Square insert 9 x 12 to 14 x 18 6450 d-38 38 ( 14 x 18 c 70 32.5 13 22.2 67 072514
6423 d ( 14 x 18 ) 9 x 12 45 20 17 22 057559 6450 d-41 41 ( 14 x 18 c 79 40 12.4 22.5 82 028580
Components and spare parts from page 482 to 490 Valid until December 31, 2021 295
