Page 292 - HAZET英文2021

Torque Technology

SYSTEM 6300 CT

SYSTEM 6300 CT

• With lockable torque setting
• Especially suitable for application in industrial series production
Adjusting the desired torque value with adjustment wrench 6399 in conjunction with HAZET torque tester 7901 E, 7902 E, 7903 E or any other
suitable device.
All torque wrenches of this line (HAZET 6391-6392) are without scale and without signal transmitter

6300 Torque wrench ∙ ±2% accuracy ∙ 6391-10 6% ∙ 1 – 12 Nm
Made in Germany
• Particularly easy to use thanks to short design
• Universal application thanks to connection for insert tools

• Accuracy ± 2 % (6391-10: 6%) of set value (in direction of actuation)
Left tightening with same accuracy possible by reversing the wrench
• Plug-and-socket connection to hold insert tools
• Permanently adjustable value
• Especially suitable for application in industrial series production
• Setting the desired torque value with adjustment wrench 6399 together with HAZET
torque tester 7901 E, 7902 E, 7903 E or any other suitable device.
All wrenches of this series (HAZET 6391-6392) are
without a scale and a signal transmitter
• With calibration certificate and serial number
• DIN EN ISO 6789-2:2017

1 Output K M 1 5 Release accuracy ! # 4
tolerance %
6391-10 ) 9 x 12 124 102 17 22 6 1 – 10 0.8 – 8.4 208951
6391-12 ) 9 x 12 124 102 17 22 2 2 – 12 1.7 – 10.1 027026
• Factory preset triggering value as requested
6391-12 V ) 9 x 12 124 102 17 22 2 2 – 12 1.7 – 10.1 145850

6300 Torque wrench ∙ ±2% accuracy ∙ 2 – 35 Nm

Made in Germany / B
• Accuracy ± 2 % of set value (in direction of actuation)
Left tightening with same accuracy possible by reversing the wrench
• Plug-and-socket connection to hold insert tools
• Permanently adjustable value
• Especially suitable for application in industrial series production
• Setting the desired torque value with adjustment wrench 6399 together with
HAZET torque tester 7901 E, 7902 E, 7903 E or any other suitable device
• All wrenches of this series (HAZET 6391-6392) are
without a scale and a signal transmitter
• With calibration certificate and serial number
• DIN EN ISO 6789-2:2017

1 Output K M 1 5 Release accuracy ! # 4
tolerance %
6391-25 ) 9 x 12 183 143 17 22 2 2 – 25 1.2 – 14.7 027040
6391-35 ) 9 x 12 183 143 17 22 2 15 – 35 8.8 – 20.6 027057
• Factory preset triggering value as requested
6391-25 V ) 9 x 12 183 143 17 22 2 2 – 25 1.2 – 14.7 145867
6391-35 V ) 9 x 12 183 143 17 22 2 15 – 35 8.8 – 20.6 145874

Components and spare parts from page 482 to 490 Valid until December 31, 2021 291
