Torque Technology Torque Technology

SYSTEM 7000 sTAC SYSTEM 7000 sTAC

SYSTEM 7000 sTAC

7000 STAC Torque wrench with built-in angle gauge ∙ electronic ∙
SmartTAC SYSTEM 7000 sTAC ∙ 1 – 1000 Nm
Made in Germany
• Smart technology – Ready for Industry 4.0.0
• HAZET Smart Technology consisting of the SmartTAC app and Bluetooth 4.1 Low • Four signals alert the user during screwing process: audible signal
Energy interface (product group 7000-2 sTAC – may be subject to national (buzzer), vibration signal, synchronous numerical display, and a 360°
approval restrictions) with flawless live data exchange to display the screwing LED display with “traffic light function” that is visible from all around
process on mobile end devices such as smartphones (smart watches) and tablet • Threshold value, pre-warning level: adjustable 50 to 99%
PCs as well as via a USB-C interface for programming the torque wrench with • Adjustable signaling, On/Off audible signal (buzzer) and vibration
built-in angle gauge and documenting screwing data via laptops and PCs
All sTAC torque wrenches can also be used • Reset function, restore to factory setting
autonomously, without the SmartTAC app • Stand-by time: adjustable 1 to 10 min.
• Unique ergonomic, user-oriented HAZET design of entire tool for professional use • Indication of battery condition and memory
• The reduction in size and integration of the PCB into the • Memory capacity, including date and time: up to 3000 measurements
main pipe, results in dimensions that allow for the small • Offers possibility to program flow charts and sets of parameters: 25 and 25
torque wrench with built-in angle gauge from 1 Nm • 2 control functions: programmable torque control for angle
• Protection class IP 40 tightening and angle control for torque tightening
Spray-water-proof display and membrane keyboard • Menu locking against unintentional change, four-digit code is personally selected
• USB-C interface for programming torque wrenches with built-in angle • Display of the software version with serial numbers,
gauge and for documentation of the screwing data via laptop and PC calibration date and service display / usage counter
• Including standard replaceable Li ion rechargeable battery, type 14650 • Menu languages: German, English, French, Italian, Chinese
/ 3.7 Volt, can be charged directly on the tool via USB-C connector • Optional: Programming and evaluation software for laptop and PC
• Including 1 metre USB 3.1 / A-C cable • SmartTAC app for Android and Apple iOS end devices for series 7000-2 sTAC
Functions: 7000 sTAC • The HAZET SmartTAC torque wrenches with built-in angle gauge of the
• Large, high-contrast illuminated, easily readable OLED 7000-2 sTAC series with Bluetooth interface have valid radio licences in all
display, dimmable and 180° rotatable EU countries as well as in Switzerland, Norway, China, India, South Korea and
• Indication of the measuring values in 13 mm font size, Turkey and may be sold there. Radio licences for Mexico, South Africa, USA and
including a rating of the screw-joint (OK / not OK) Canada are currently in preparation.
• Display deviation in right and left torque: from ±1% / ±1 digit Other countries on request.
• Display deviation in right and left rotation angle: ±1% / ±1° • For countries without radio licences, we offer the 7000-5 sTAC series
• Rotation angle range adding: 0 to 999° SmartTAC torque wrench without a Bluetooth interface. These can
be connected to a laptop and PC via a USB port and to the optional
• Torque tolerance for OK display (green): adjustable ±1 to 10% programming and evaluation software. It is not possible to use the SmartTAC
• Rotation angle tolerance for OK display (green): adjustable 1 to 90° app for mobile devices due to the lack of a Bluetooth interface.
• Choice of torque measuring units: Nm, lbf ft, lbf in or kgf m • With Bluetooth function
• Lets you select or program the effective length for other insert tools from • Release accuracy tolerance according to ISO 6789-2:2017
0 to 250 m (requirement for correct torque / rotation angle measurements)

B
288 Valid until December 31, 2021 Components and spare parts from page 482 to 490
