241SB-...
CUTTING AND FLARING SET

³ 3 pcs.
³ for beading of copper and light alloy tubes
³ flaring cone 90 ° hardened,
corresponds to 45 ° at the tube
³ body made of zinc die-cast
³ jaws made of steel, smooth inside, phosphated
³ pipe cutter with a cutting wheel and two guide rollers
³ ergonomic rotary knob with integrated trim knife
³ painted, gunmetal finished spindle
³ cutting wheel made of high alloy special steel

Code Number Contents Pieces Weight/g
U V
0241020016000 241SB-1 Flaring tool with jaw 241-1 for Tubes outside ø 4, 4,75, 6, 8, 10, 12, 14 mm 1 2600
Tubing cutter 179-35
0241020096000 241SB-9 Flaring tool with jaw 241-9 for Tubes outside ø 15, 16, 17, 18, 19 mm 1 2590
Tubing cutter 179-35
406-...
TUBE BENDING PLIER
³ for bends up to 90°
³ for thin-walled bendable steel pipes or copper pipes
³ with plastic handle protectors

Code Number l/mm for pipes up to Ø mm Pieces Weight/g
T U V
0406000120000 406-12 515 12 1 1300
0406000150000 406-15 665 15 1 2400
0406000160000 406-16 665 16 1 2400
0406000220000 406-22 950 22 1 5600

407
TUBE BENDING PLIER
³ for dimensions from 4,75 – 10 mm (3/16“ – 3/8“) Ø up to 90°
³ for soft copper pipes EN 1057, Ne-metal pipes as well as thin-walled precision steel pipes and brake lines
³ with 2 turnable bending dies 3/16”, ¼” and 5/16”, 3/8”

Code Number l/mm for pipes up to Ø mm Pieces Weight/g
T U V
13 0407000001000 407 260 4,75-10 1 580
