Page 395 - ELORA-Tool_Catalogue_E95

5001
PNEUMATIC IMPACT WRENCH 3/4“, 1900 NM

³ extremely powerful and ultra light
³ max. torque 1900 Nm at just 3,4 kg weight 20
³ with vibration-damped composite housing
³ non-slip cold insulated handle 3/4"
³ exhaust air guided through handle
³ always full capacity when loosening
³ clockwise- 3-step torque regulation when tightening
³ clockwise/counter clockwise performance regulation
protected in rear motor plate
³ with high-performance twin-hammer mechanism
³ air inlet thread 3/8‘‘
³ operating pressure 6,3 bar
³ Tightening torque max. 1900 Nm
³ Maximum loosening 2730 Nm
³ max. sound level 95 dB (A) Lp A
³ average air consumption 280 l/min
³ recommended hose inner-Ø 13 mm
³ vibration acceleration 12,3 m/s²
³ including brass nipple

Code Number l/mm Pieces Weight/g
T U V
5001000000000 5001 3/4‘‘ 240 1 4180

5002
PNEUMATIC IMPACT WRENCH 1‘‘ WITH LONG SPINDLE, 2450 NM
³ extremely powerful with optimal working weight
³ max. torque 2450 Nm at just 7,2 kg weight 25
³ with vibration-damped composite housing
³ non-slip cold insulated handle 1"
³ swivel air inlet thread and exhaust air guided through handle
³ always full capacity when loosening
³ clockwise- 3-step torque regulation when tightening
³ clockwise/counter clockwise performance regulation
protected in rear motor plate
³ with super high-performance twin-hammer mechanism
³ air inlet thread 1/2‘‘
³ operating pressure 6,3 bar
³ Tightening torque max. 2450 Nm 10
³ Maximum loosening 3500 Nm
³ max. sound level 95 dB (A) Lp A
³ average air consumption 370 l/min
³ recommended hose inner-Ø 13 mm
³ vibration acceleration 52,2 m/s²
³ including brass nipple

Code Number l/mm Pieces Weight/g Gewicht/g
T U V V
5002000000000 5002 1‘‘ 185 500 1 9720

info@elora.de www.elora.de 395
