PROFESSIONAL PNEUMATIC TOOLS

5003, 5004
PNEUMATIC IMPACT WRENCH MINI, 450 NM

³ extremely handy impact wrench with only 160 mm length
³ for work at difficult accessible areas 10 12,5
³ maximum performance at minimum weight
³ with vibration-damped composite housing 3/8" 1/2"
³ non-slip cold insulated handle
³ exhaust air guided through handle
³ always full capacity when loosening
³ clockwise 3-step torque regulation when tightening
³ clockwise/counter clockwise performance regulation protected in rear motor plate
³ with high-performance twin-hammer mechanism
³ air inlet thread 1/4‘‘
³ Operating pressure 6,3 bar 5003
³ Tightening torque max. 450 Nm
³ max. sound level 95 dB (A) Lp A
³ average air consumption 100 l/min
³ recommended hose inner-Ø 8 mm
³ vibration acceleration 5,9 m/s²
³ including brass nipple

5004

Code Number l/mm Pieces Weight/g
T U V
5003000000000 5003 1/2‘‘ 160 1 1575
5004000000000 5004 3/8‘‘ 160 1 1563

5000
PNEUMATIC IMPACT WRENCH 1/2“, 1350 NM
³ extremely powerful and ultra light
³ max. torque 1350 Nm at just 2 kg weight 12,5
³ with vibration-damped composite housing
³ non-slip cold insulated handle 1/2"
³ exhaust air guided through handle
³ always full capacity when loosening
³ clockwise- 3-step torque regulation when tightening
³ clockwise/counter clockwise performance regulation
protected in rear motor plate
³ with high-performance twin-hammer mechanism
³ air inlet thread 1/4‘‘
³ operating pressure 6,3 bar
10 ³ Tightening torque max. 1350 Nm
³ Maximum loosening 1850 Nm
³ max. sound level 95 dB (A) Lp A
³ average air consumption 170 l/min
³ recommended hose inner-Ø 8 mm
³ vibration acceleration 7,9 m/s²
³ including brass nipple

Code Number l/mm Pieces Weight/g
T U V
5000000000000 5000 1/2‘‘ 200 1 2280
