4530-...
ELECTRONIC SIDE CUTTER ESD

³ for all work with electrostatic endangered components
³ oval head, maximum stability under load by additional inductive hardening and box joint,
with double opening leaf spring, polished and high gloss gunmetal-finish,
with 2-C ESD handles, surface resistance 10 -10 Ohm
9
6
³ M= with bevel
³ F= with fine bevel
³ O= without bevel
³ cutting edge hardness 61-63 HRC
³ ELORA-high grade tool steel C60 / 1.0601
³ DIN ISO 9654, ESD: DIN IEC 614340-5-1

Code Number Hard mm / AWG Medium mm / AWG Soft mm / AWG l/mm Pieces Weight/g
T U V
4530020001000 4530-M E 2K 0,4 / 26 1,0 / 18 1,5 / 15 125 1 98
4530010001000 4530-F E 2K - 1,0 / 18 1,5 / 15 125 1 95
4530030001000 4530-O E 2K - 0,8 / 20 1,5 / 15 125 1 98

4540
ELECTRONIC SIDE CUTTER WITH WIRE TRAPPING SPRING ESD
³ with trapping wire to cut off wire, for all work with electrostatic endangered components
³ oval head with wire trapping spring, with bevel, maximum stability under load by additional
inductive hardening and box joint, with double opening leaf spring, polished and high gloss
6
gunmetal-finish, with 2-C ESD handles, surface resistance 10 -10 Ohm
9
³ cutting edge hardness 61-63 HRC
³ ELORA-high grade tool steel C60 / 1.0601
³ DIN ISO 9654, ESD: DIN IEC 614340-5-1

Code Number Hard mm / AWG Medium mm / AWG Soft mm / AWG l/mm Pieces Weight/g
T U V
4540020001000 4540-M E 2K 0,4 / 26 1,0 / 18 1,5 / 15 125 1 96 07

4730
ELECTRONIC SIDE CUTTER ESD
³ for all work with electrostatic endangered components
³ oval head, with bevel, maximum stability under load by additional inductive hardening
and box joint, with double opening leaf spring, polished and high gloss gunmetal-finish,
9
with 2-C ESD handles, surface resistance 10 -10 Ohm
6
³ cutting edge hardness 61-63 HRC
³ ELORA-high grade tool steel C60 / 1.0601
³ DIN ISO 9654, ESD: DIN IEC 614340-5-1

Code Number Hard mm / AWG Medium mm / AWG Soft mm / AWG l/mm Pieces Weight/g
T U V
4730020001000 4730-M E 2K 0,4 / 26 1,0 / 18 1,5 / 15 120 1 101

4560
ELECTRONIC SIDE CUTTER ESD
³ for all work with electrostatic endangered components
³ oval head, with bevel, maximum stability under load by additional inductive hardening
and box joint, with double opening leaf spring, polished and high gloss gunmetal-finish,
9
with 2-C ESD handles, surface resistance 10 -10 Ohm
6
³ cutting edge hardness 61-63 HRC
³ ELORA-high grade tool steel C60 / 1.0601
³ DIN ISO 9654, ESD: DIN IEC 614340-5-1

Code Number Hard mm / AWG Medium mm / AWG Soft mm / AWG l/mm Pieces Weight/g
T U V
4560020001000 4560-M E 2K 0,7 / 21 1,5 / 15 2,0 / 12 135 1 155
