OIL FILTER WRENCH Specialized tool for removing oil filter.
For minicars and ordinary vehicles (FWJ-94).

Dimensions
Sq.dr Diameter fits Qty./Carton Weight 9.5
Models (mm)
(mm) (mm) (g)
L (Generally) (Store Center) mm
FWJ-94 9.5 φ 64 ～ φ 94 34.5 1 3 230 3/8
Example
FWJ-94

CAUTION
● Do not use wrenches if crack, wear or distortion is found.

Dimensions For minicars and ordinary vehicles (FWC-115).
Sq.dr Diameter fits Qty./Carton Weight
Models (mm) For large truck (FWC-160) .
(mm) (mm) (g)
L (Generally) (Store Center)
FWC-115 12.7 φ 70 ～φ 115 62.0 1 3 370 12.7 FWC-115
FWC-160 12.7 φ 115 ～φ 160 43.2 1 3 430
mm
Example 1/2

FWC-115
FWC-160
CAUTION
● Do not use wrenches if crack, wear or distortion is found.
FWC-160
TORQUE WRENCH for WHEEL NUT Calibration Certificate Included

Test Report Traceability
Chart
Single purpose type torque wrench for automobile wheel nut which torque is setted according to car model (torque can not be changed).
Optimum length that does not interfere with the tires and hands.
When preset torque has been reached, the wrench will make a click sound and have a light shock on hands.

12.7 Example
mm
1/2

T4MP85 T4MP103

Setting Sq.dr Dimensions (mm) Applicable model Qty./
Torque
Carton
A
Models wrench （N・m） Units (mm) (Generally) Weight Case size
torque
(kg)
T
L
Car type
H
B
19
T4MP85 T4MP100 85 N・m 12.7 36.0 30.4 14.0 369 SUZUKI / NISSAN minicar A/F width 1 0.68 505 × 97 × 70
T4MP103 T4MP140 103 N・m 12.7 36.0 30.4 14.0 432 TOYOTA / DAIHATSU 21 1 0.80 505 × 97 × 70
T4MP108 T4MP140 108 N・m 12.7 36.0 30.4 14.0 432 HONDA / NISSAN 19 1 0.80 505 × 97 × 70
● N・m specification Accessory ̗ 0/-: /N
● Torque Accuracy ( ± 3%) Calibration cert. (with traceability) 1 ̡
Instruction manual 1 ̩
Resin case 1 ̝ "
Expiration date of calibration cert. (The validation only when torque is set by our company)
1. When not in use, the product can stay up to 3 years after 2. f the usage started after 3 years from calibration date, it can be
I
calibration date mentioned in the certificate. used up to 1 year since the first usage or up to 100,000 tightening
times.
Check & Repair
■ Be sure to clearly indicate the torque value for repair, inspection, ■ naccuracy may occur if not used for a long time or inappropriate use of tool.
I
calibration certificate issuance, etc. Please contact your distributor regularly for accuracy check (with service charge)
■ Accuracy range after repair will be ± 4%. ■ Torque devices require regular inspection (once a year or 100,000 times
■ Please contact your distributor in case of experiencing tool malfunction afterwards). Checking service is available with service charge.
such as no clicking sound, slight force, etc. (with service charge) ■ For more information about tool handling, please contact your distributor.
405
