PARTS WASHERS: AQUEOUS BASED
CLEANING

PBC55-1

PBC57A PBC58 PBC55-3

Electric/Heavy-Duty
SHOP • High-pressure aqueous parts washer effectively cleans engine blocks, cylinder heads,
transmission cases and small parts
• Cycle time can be adjusted from 0–60 minutes
• Five RPM turntable is driven by a #40 chain for rotation without slippage; extends 18ʺ
for easy part loading
• Sprocket drive and turntable motor have dual sealed bearing shafts for longevity
and strength
• Includes a 25 lb pail of YADW896B Biodegradable Soap Concentrate
• Also includes an integral oil skimmer and pump reservoir filter to remove oil and
grease, helping maintain cleaning effectiveness
• Double intake filtration system has a perforated steel screen filter with a sludge trap
• Rugged 12-gauge steel construction with solid welded seams
Specifications PBC57A PBC58 PBC57A High-Pressure Automatic Parts Washer
Depth, inches (mm) 35 (889) 35 (889) • Automatically cleans parts with a 45 PSI heated soap
Reservoir Capacity, gal 60 60 solution spraying from 20 high-pressure nozzles
Electrical Requirements 230 V AC, 60 Hz 230 V AC, 60 Hz, 60 A at 40 GPM
Pump Motor, HP 2 3 PBC58 High-Pressure Heavy-Duty
Output Pressure, PSI 45 45 Automatic Parts Washer
• Automatically cleans parts with a 45 PSI heated soap
Volume,
gallons per hour 2,700 2,880 solution spraying from 24 high-pressure nozzles
Heater, watts 9,000 9,000 at 42 GPM
Open Height, inches 69 — PBC55-1 Parts Basket
• Perforated steel basket is perfect for holding small parts
Inside Dimensions,
inches 35 W x 35 D x 41 H 36 W x 35 D x 54 H PBC55-3 Parts Tree
Overall Dimensions, • Welded steel tube rack for hanging smaller parts
inches 53 W x 43 D x 69 H 53 W x 43 D x 81 H PBC58-3 Parts Tree
European Model: PBCH57AEUR† (230 V AC, 50 Hz) • 45ʺ tall rack for hanging smaller parts
†

Air Agitated Immersion Cleaner
PBD16 Air Agitated Immersion Cleaner
• Use with parts degreaser or carburetor cleaner
• Heavy-duty air motor rotates the basket in both directions
• Cover has a locking band that seals the unit
• 4-1/2ʺ deep basket has a hook for draining parts from top
of pail and holes for holding extra-small parts
• Overall height of 32ʺ
• Base diameter of 14-1/2ʺ
• Requires 5 CFM @ 100 PSI

844 PBD16

Snapon.com 1.877.762.7664
