PUNCHES AND CHISELS
PUNCHES/CHISELS/HAMMERS
Punches and Chisels
The anvil end on heads of Snap-on punches and chisels are machined to a modified parabolic curve. This design
®
directs the striking force to the center of the tool head to allow slow metal displacement. The parabolic curve controls
mushrooming to reduce chipping and splitting. Heads should be redressed to their original shape with hand files as
necessary. The tough alloy steel is machined and differentially heat treated for optimum performance. The hardness of the
striking head is reduced to help toughness and add qualities that result in a slower mushrooming of the striking surface.

Soft Grip Punches and Chisels
• Ergonomic soft grip handle provides a powerful • Feature a comfortable yet extremely durable split-proof
grip, improves the thermal sensation in cold work composite handle that provides a non-slip surface and
environments and reduces strike vibration safety shoulder to prevent contacting the metal blade
• Semispherical striking area controls mushrooming to • Manufactured from special alloy steel that is
help reduce chipping and splitting differentially heat treated to increase durability
• Cutting edges on chisels are hand ground to consistently • Forged blade is precision ground and honed for strength
produce a quality edge and blade edge maintenance
• Black oxide coated • Designed for use with steel and steel-faced hammers
• Chisels are intended for woodwork applications or
scraping applications

PPCSG710 CHSL400R

Set PPCSG710 Set CHSL400
Contains: Contains:
Length, Point/ Edge, Tip Width, inches
Stock No. Description Stock No. Description
inches inches (mm)
PCSG812 Flat Chisel 6-1/8 3/8 • CHSL25 Striking Chisel 1/4 (6.35) •
PCSG816 Flat Chisel 6-1/8 1/2 • CHSL50 Striking Chisel 1/2 (12.7) •
PCSG820 Flat Chisel 6-1/8 5/8 • CHSL75 Striking Chisel 3/4 (19.05) •
PPSG103 Pin Punch 6-1/8 3/32 • CHSL100 Striking Chisel 1 (25.4) •
PPSG105 Pin Punch 6-1/2 5/32 •
PPSG106 Pin Punch 6-1/2 3/16 • Colors Available
PPSG203 Starter Punch 6-1/8 3/32 •
PPSG205 Starter Punch 6-1/8 5/32 •
PPSG206 Starter Punch 6-1/8 3/16 • Red Orange Green
G
O
PPSG4 Center Punch 6-1/8 3/16 • ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS

GA1
PPC704BK
Bushing Cutter
®
Oval Bearing Race Punches GA1 Bushing Cutter (Blue-Point )
• Made of 1/2ʺ octagonal stock with a 7/16 x 1/8ʺ bit
High alloy steel makes these tools PPC704BK • Curved bit pushes material away from work
ideal for stubborn bearing races. Set • 7-1/4ʺ long
Contains:
Stock No. Description
PPC10LB 10ʺ Oval Bearing Race Punch •
PPC14LB 14ʺ Oval Bearing Race Punch •
PPC20LB 20ʺ Oval Bearing Race Punch •
PPC6LB 6ʺ Oval Bearing Race Punch •
YA879A YA900

Automatic Centering Punches
YA879A Heavy-Duty YA900 4-3/4ʺ
Automatic Center Punch Automatic Center Punch
®
®
(Blue-Point ) (Blue-Point )
• Single-hand operation • Strikes blow when
Gasket Punch Set PGH8A • Design eliminates need pressure is applied, no
hammer needed
for striking with hammer
PGH8A ‡ 11 pc Gasket Punch Set (Blue-Point ) • Adjustable spring • Cap adjusts force of blow
®
• Cut holes in gaskets and other soft materials tension cap • 7/16ʺ diameter
• Includes 5-3/8ʺ long mandrel and (10) punches • Hardened-steel point • 4-3/4ʺ long
(1/4, 5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 3/4, 7/8 and 1ʺ) is replaceable
410 • Includes storage case • 1/2ʺ diameter
