LOCKING PLIERS

LP5SLIM LP7SLIM LP6LN PLIERS

LP10WR LP404
LP10GRV
A “V” groove
houses round
objects, preventing
lateral movement.
LP Series
• Spring-loaded release lever allows quick “no-pinch” release
• Locking nut secures jaw opening for repeat jobs
• Larger jaw capacity to hold larger objects
• Jaws feature a greater surface area and broader teeth for Set LP404
more secure gripping Contains:
Stock No. Description Jaw Capacity, inches (A) Length, inches (B)
LP5SLIM Locking Pliers 1-5/32 5
LP7SLIM Locking Pliers 1-5/8 7
LP5WR Curved Jaw with Cutter Locking Pliers 1-5/32 5 •
LP6LN Long Nose Locking Pliers 2-1/8 6 •
LP7WR Curved Jaw with Cutter Locking Pliers 1-5/8 7 •
LP10WR Curved Jaw with Cutter Locking Pliers 2-7/16 10 •
LP7R Locking Pliers 1-5/8 7
LP10R Locking Pliers 2-7/16 10
LP10LN Locking Pliers 2-3/4 10
LP10GRV Grooved Jaw Locking Pliers 1-5/8 10
LP5SLIM Locking Pliers LP10GRV Grooved Jaw Locking Pliers
• Used for removal of socket-style sway bar links • Longitudinal V-groove section provides three points of
• Thinner jaws fit between the stabilizer bar and contact preventing lateral movement while working
stabilizer link to allow a socket to be used for • Specially tapered groove means the larger the work
nut removal piece, the larger the groove section that holds it
• LP7SLIM Applications: 2002-2004 Dodge Caravans, • Convex tooth section of the mobile jaw pushes flat
®
Chrysler Town and Country and any other vehicles work pieces against the large, flat fixed jaw for
®
®
with non-greaseable sway bar links tighter clamping
• Recessed area of the mobile jaw allows angled objects
to be held and clears small obstacles
• Serrated milled teeth provide a positive grip on
different shaped objects
®
Locking Pliers/Standard Grip (Blue-Point )
• Made from high grade heat-treated steel alloys, the hardened precision
ground jaws “lock” onto work pieces that are difficult to hold
• Adjusting screws ensure fine
adjustments for precise gripping
• Soft grip series improves comfort while Set BLP404 BSGLP404
resisting damage from oil and grease Contains:
Jaw Capacity, Length,
Stock No. Description Grip Style
inches (A) inches (B)
BLP5 Curved Jaw Standard 1.125 5 •
BLP7 Curved Jaw Standard 1.625 7 • BLP404 BSGLP404
BLP10 Curved Jaw Standard 1.875 10 •
BLP6LN Long Nose Standard 2.25 6 •
BSGLP5 Curved Jaw Soft 1.125 5 •
BSGLP7 Curved Jaw Soft 1.625 7 •
BSGLP10 Curved Jaw Soft 1.875 10 •
BSGLP6LN Long Nose Soft 2.25 6 • BSGLP6LN BLP7

397
HAND TOOLS
• Plastic-coated handles on these pliers and cutters do not protect against electric shock
397
• Read safety precautions on pages W1 to W4
