REVERSIBLE RATCHETING COMBINATION (Blue-Point )
®
WRENCHES
Flex Head Ratcheting Combination/Midget Handle, BOERMSF712
®
15° Offset, mm (Blue-Point ) Set
Contains:
A B C D E
8 BOERMSF8 17.8 17.7 6.5 4.0 94 •
9 BOERMSF9 19.5 20.0 7.4 4.0 98 •
10 BOERMSF10 21.5 21.9 8 5 103 •
11 BOERMSF11 22 23.9 8.5 5.5 108 •
12 BOERMSF12 23.5 25 9 5.5 111 •
13 BOERMSF13 25 25.9 10 6.3 115 •
14 BOERMSF14 27 29.9 10 6.5 120 •
15 BOERMSF15 28.5 31.1 11 7 124 •
16 BOERMSF16 30.5 33.6 11 7 128 •
17 BOERMSF17 32 36.5 12 7 133 •
18 BOERMSF18 34.5 38.5 12 8 140 •
19 BOERMSF19 36.5 38.7 12.9 8.7 147 •
®
BOERMSF712 ASME B107.100 Set includes storage bag.
Flex Head Ratcheting Combination/Midget Handle, BOERSF708
15° Offset, inches (Blue-Point ) Set
®
Contains:
A B C D E
5/16 BOERSF10 11/16 11/16 1/4 5/32 3-11/16 •
3/8 BOERSF12 27/32 7/8 5/16 3/16 4-1/16 •
7/16 BOERSF14 7/8 15/16 11/32 7/32 4-1/4 •
1/2 BOERSF16 31/32 1-1/32 13/32 1/4 4-17/32 •
9/16 BOERSF18 1-1/16 1-3/16 13/32 1/4 4-23/32 •
5/8 BOERSF20 1-3/16 1-5/16 7/16 9/32 5-1/32 •
11/16 BOERSF22 1-1/4 1-7/16 15/32 9/32 5-1/4 •
3/4 BOERSF24 1-7/16 1-17/32 1/2 11/32 5-25/32 •
BOERSF708 ASME B107.100 Set includes storage bag.
®
RATCHETING WRENCH ADAPTORS
Ratcheting Wrench Adaptors Stock No. Configuration Use with Ratcheting
• Converts a ratcheting wrench into a ratchet Wrench Size
• Used with reversible ratcheting box wrenches, such as RWA1 1/4ʺ Drive 13 mm
the SOXRR, SOXRRM, BOERM, BOERMF and BOERMS Series RWA2 3/8ʺ Drive 16 mm
• Can be used with the combination ratcheting box wrenches RWA3 1/2ʺ Drive 19 mm
such as the OXR, OXRM, OXIR, and OXIRM series RWA4 1/4ʺ Hex 13 mm
• Reverse lever on wrench is used to secure or remove RWA1FR 1/4ʺ Drive 1/2ʺ
RWA2 adaptor from the wrench RWA2FR 3/8ʺ Drive 5/8ʺ
• Push button on adaptor is used to release the socket RWA3FR 1/2ʺ Drive 3/4ʺ
RWA4FR 1/4ʺ Hex 1/2ʺ
RATCHETING BOX
Standard Handle Spline, inches
Snap-on spline wrenching tools have been developed to Chrome tools comply with Military Spec. MS-33787 and
®
service high-tensile strength spline nuts and bolts widely MIL-W-8982. The unique spline wrenching configuration
used on both military and commercial aircraft. Precise can also be used on ordinary 6- and 12-point fasteners
®
®
radial spline teeth engage the fastener teeth over a wider with an advantage similar to the Snap-on Flank Drive
area to minimize stress, and allow application of high torque wrenching system.
to reduce risk of damage to the fastener or to the tool.
Number of
Stock No. A C E
Gear Teeth
#8–#10 1/4–5/16 RES810C 19/32–43/64 3/8 4-1/2 14–15
#12–#14 3/8–7/16 RES1214C 1-1/64–1-5/32 1/2 6-7/8 17–18
#18–#20 9/16–5/8 RES1820C 1-19/64–1-7/16 1/2 8-1/8 19–21
#26–#30 13/16–15/16 RES2630C 1-13/32–1-37/64 1/2 9-1/4 21–24
RES2630C
