RATCHET HEADS/HANDLES
TOOLS GL872 Ratchet Heads, Sealed (3/4ʺ) Teeth Swing Arc 1-1/4 2-1/2 5-15/16 RKRQC4

L872
Gear
B
C
Description
Stock No.
A
Repair Kit
Sealed Ratchet Head
11°
32
L872
32
2-1/2
1-1/4
11°
Sealed Ratchet Head
5-15/16
RKRQC4
GL872
DRIVE L872H Handles, Chrome (3/4ʺ) Description 13/16 19-1/4 15/16
C
Stock No.
B
A
Short 19-1/4ʺ Handle (lock button both ends)
L872H
15/16
Long 36ʺ Handle (lock button end/knurled end)
1-1/8
36
L872RM
Short 19-1/4ʺ Handle (lock button end/knurled end)
1-1/8
19-1/4
15/16
L872RJ
Head and Handle Combinations (3/4ʺ)
L872RM
Heads Using 13/16" (small) Heads using 15/16" (large)
diameter handle holes
L872
L52B diameter handle holes L8112A
Sealed Ratchet Head
Breaker Bar Head
Sliding Head
3/4” (lock button end/knurled end) L872H — L872RJ — L872H
L872RJ
Short 19-1/4ʺ Handle
(lock button both ends)
Short 19-1/4ʺ Handle
L872RJ
Long 36ʺ Handle
—
L872RM
L872RM
(lock button end/knurled end)
®
®
DRIVE HANDLES ASME /ANSI B107.10
Breaker Bar, Chrome (3/4ʺ)
Head Only A B C Use with Handle
L8112A 15/16 1-9/16 3-11/16 L872RM or L872RJ
L8112A
Sliding T-Handle, Chrome (3/4ʺ)
Stock No. A B
L52B 1-1/2 2-5/16
3/4ʺ Drive 2-5/16ʺ Head Depth Sliding T-Handle Head
• Designed for heavier applications
• Can be used as a T-handle or as an offset wrench
L52B
• Spring-and-friction ball holds head in position
• Use with L872H handle
SOCKET/RATCHET ACCESSORIES
Extensions/Lock Button (3/4ʺ)
L32 Stock No. Industrial Stock No. A B
L32 GL32 15/16 3
L42 GL42 15/16 5
L62 GL62 15/16 8
L122 GL122 15/16 16
GL42
252
Snapon.com 1.877.762.7664
