TRIPLE SQUARE BIT SOCKETS

STSM10LE 1/2”

Triple Square/Standard, mm, Chrome (1/2ʺ) TSS7KIT Set TSS7KIT
Contains:
Stock No. A B
Standard Length 10 STSM10E 88.9 STSM10E2 •
12 STSM12E 109.5 STSM12E2 •
14 STSM14E 108.0 STSM14E2 •
16 STSM16E* 108.0 STSM16E2 •
18 STSM18E 108.0 STSM18E2 • DRIVE
Long 10 STSM10LE 156.3 STSM10LE2 •
12 STSM12LE 147.6 STSM12LE2 •
*Tamper resistant Set shown includes storage tray.
STSM12E 1/2ʺ Drive Metric 12 mm Standard Triple STSM18E 1/2ʺ Drive Metric 18 mm Standard Triple
Square Bit Socket Driver Square Bit Socket Driver
• Applications include removal/installation of cylinder • Applications include removal/installation of rear axle
®
head bolts on Mercedes-Benz , rear toe adjustment bolts of 2006 VW Jetta and Golf vehicles
®
®
®
®
on 1999 and newer Audi A6 and axle shaft bolts on STSM10E 1/2ʺ Drive Metric 10 mm Standard Triple
®
®
new VW vehicles Square Bit Socket Driver
STSM14E 1/2ʺ Drive Metric 14 mm Standard Triple • Double hex bit sockets and triple square bit sockets
Square Bit Socket Driver cannot be interchanged between applications
®
®
• Applications include 2003 and later VW Touareg front • Triple square bit sockets have 90° corners and double
®
®
axle bolts, 2003 and later Porsche Cayenne front hex bit sockets have 120° corners TOOLS
®
®
®
axle bolts, various Audi /VW axle bolts and Audi TT • Using a triple square bit socket in a double hex bit
differential mount bolts and transmission drain plugs application will strip the bolt head
STSM16E 1/2ʺ Drive Metric 16 mm Standard Triple • In general, triple square bit sockets are used on
Square Bit Socket Driver European vehicles
®
• Applications include Audi TT clutch and belly pan, • Pinless bits (no roll pin) provide a solid fit, are easily
®
®
various VW /Audi transmission drain plugs (tamper- replaced, and have no hole to collect dirt and grit
resistant), 2003 and later VW Touareg front and rear • Bits feature natural oil coat finish to protect
®
®
brake caliper bolts, 2003 and later Porsche Cayenne against corrosion
®
®
brake caliper bolts, Detroit Diesel flywheel bolts and
®
front crank pulley on 900 and 4000 engines and head
bolts on 900 engines
Triple Square/Stubby, mm, Chrome (1/2ʺ)
• Pinless bits (no roll pin) provide a solid fit, are easily replaced,
and have no hole to collect dirt and grit
• Bit sockets are chrome plated
• Bits feature natural oil coat finish to protect against corrosion
• Double Hex socket drivers and Triple Square socket drivers cannot be 305STSMSE
interchanged between applications
• Using a Triple Square tool in a Double Hex application will strip the bolt head
• In general, Triple Square tools are used on European vehicles and Double Hex Set 305STSMSE
tools are used on Asian vehicles Contains:
Stock No. A B
10 STSM10SE 59.4 STSM10SE2 •
12 STSM12SE 59.4 STSM12SE2 •
14 STSM14SE 63.2 STSM14SE2 •
16 STSM16SE 68.1 STSM16SE2 •
18 STSM18SE 69.8 STSM18SE2 •
Set includes magnetic storage tray.
STSM10SE 1/2ʺ Drive Metric 10 mm Triple Square Bit Socket Driver
• Applications include removal/installation of cylinder head bolts, drive shaft bolts and various other applications on
®
®
VW , Audi and Mercedes-Benz vehicles
®
STSM12SE 1/2ʺ Drive Metric 12 mm Triple Square Bit Socket Driver
• Applications include removal/installation of head bolts and axle shaft bolts on VW , Audi and Mercedes vehicles
®
®
®
STSM14SE 1/2ʺ Drive Metric 14 mm Triple Square Bit Socket Driver
STSM16SE 1/2ʺ Drive Metric 16 mm Triple Square Bit Socket Driver
• In general, Triple Square tools are used on European vehicles and Double Hex tools are used on Asian vehicles
STSM18SE 1/2ʺ Drive Metric 18 mm Triple Square Bit Socket Driver
• In general, Triple Square tools are used on European vehicles and Double Hex tools are used on Asian vehicles
233
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
