IMPACT ACCESSORIES

Extensions

• Ideal for use on transmission bellhousing bolts, transaxle and suspension service
• Pull-back collar for fast and easy attachment and removal of sockets 1/2”
• Knurled release collar provides easy one-hand operation
• Single body construction for maximum strength and locking mechanism specifically for impact use
• Female drive end recessed to accommodate newer style impact guns

Extensions/Locking Set 303IMXL 303AIMXL
Contains:
Stock No. A B
IMXL32 5/8 3-1/2 •
IMXL52 5/8 5 •
IMXL102 5/8 10 • DRIVE
IMXL182 5/8 18 •
IMXL242 5/8 24 • 303IMXL
IMXL312 5/8 31 •
Sets include storage tray.

Extensions/Snap Ring Retention, Industrial Set 304IMX
Contains:
Stock No. A B
IMX32B 5/8 3 •
IMX52 21/32 5-3/32 •
IMX112 21/32 11-1/4 •
Set includes IP80D and storage tray. TOOLS
304IMX 4 pc 1/2ʺ Drive Impact Extension Set
• Includes (3) extensions (3, 5-3/32 and 11-1/4ʺ) plus (1) universal joint in a storage tray
304IMX

Extension Adaptor
Stock No. A B C D
IMXA42 3/8 1/2 1/2 4
IMXA42

Universal Joints (Impact)
Stock No. Socket Attachment A B
IP80D Pin Type 1-1/4 2-3/4
IP800 Ball Type 1-1/4 2-3/4
Set includes storage tray.
202IP 2 pc Combination Drive Impact Universal Joint Set
• Includes 3/8ʺ drive and 1/2ʺ drive Impact Swivel Universal Joints
202IP

Swivel Extensions (1/2ʺ)
• Laser-welded pivot pin allows smooth, full 30° swivel action for efficient power transfer
• Manufactured from special alloy steel and heat treated for optimum strength and durability
• Provides versatility for the technician as they can use any shallow, semi-deep, deep,
6-point, 12-point, metric or SAE impact socket, and are not limited to just one size
IPSX6 1/2 Drive 6ʺ Swivel Impact Extension
• Removes and installs bolts/nuts with a 1/2ʺ impact gun IPSX6
• Technician can use any shallow, semi-deep, deep, 6-point, 12-point, metric or SAE impact
socket with this extension
• Employs friction ball socket retention method
• Manufactured from special alloy and heat-treated for optimum strength and durability
IPSXL6 1/2 Drive 6ʺ Swivel Impact Pinned Extension
• Removes and installs bolts/nuts with a 1/2ʺ impact gun IPSXL6
• Technicians can use any shallow, semi-deep, 6-point, 12-point, metric or SAE impact socket
with this extension
• Manufactured from special alloy and heat-treated for optimum strength and durability
• Laser welded pivot pin allows smooth, full 30° swivel action for efficient power transfer
• Employs lock button engagement in side lock holes of socket ensuring positive retention
235
• Do not use chrome or industrial finished hand tools with power impact drivers
• Read safety precautions on pages W1 to W4
