FLANK DRIVE SOCKETS
®

Shallow Universal, Inches, Chrome Set 307SUY 1/2”
Contains:
A B C D E
9/16 SU18 27/32 15/16 1-19/64 27/32 15/16 •
5/8 SU20 15/16 15/16 1-21/64 2-15/32 3/8 •
11/16 SU22 1-1/16 1-1/16 1-15/32 2-9/16 7/16 •
3/4 SU24 1-1/8 1-1/8 1-43/64 2-7/8 1/2 •
13/16 SU26 1-3/16 1-1/8 1-3/4 2-15/16 9/16 •
7/8 SU28 1-1/4 1-1/8 1-3/4 2-15/16 9/16 •
15/16 SU30 1-5/16 1-1/8 1-13/16 3 9/16 • SU24
®
®
ASME /ANSI B107.10M Set includes storage tray. DRIVE
TORX SOCKETS
®

®
TORX Plus with Countersink
• SLEPL Series of TORX Plus Sockets
®
with shallow countersink are designed
®
for use on external TORX Plus low-
profile head fasteners to fully engage
the fastener head
• Manufactured from special alloy steel SLEPL200 GSLEPL200 213AFLEY TOOLS
• Precision forged and heat treated for

®
optimum strength and durability Shallow TORX , Chrome
Industrial
Stock No. A B C Stock No. A B D
Stock No.
18EP SLEPL180 — 29/32 15/16 1-1/2 E14 SLE140 21/32 7/8 1-1/2
20EP SLEPL200 GSLEPL200 15/16 11/16 1-1/2 E16 SLE160A 23/32 27/32 1-1/2
22EPL SLEPL220 — 15/16 11/16 1-1/2 E18 SLE180A 27/32 7/8 1-1/2
24EPL SLEPL240 — 15/16 11/16 1-1/2 E20 SLE200A 15/16 7/8 1-1/2
E24 SLE240 1-1/16 1 1-1/2
®
SLEPL200 1/2ʺ Drive 20EPL TORX Plus with Countersink Socket
• For removal and installation of low-profile drive plate and flywheel Set includes magnetic storage tray.
®
®
bolts on QR25 Nissan motors with automatic transmissions 213AFLEY 13 pc Combination Drive TORX
• Similar to the J-45816 Nissan specialty tool Shallow Socket Set
®
®
• For flywheel bolts on Nissan QR25 motors with manual transmissions • Includes (13) sockets– 1/4ʺ drive (E4–E10),
®
use the FTX50TPE 3/8ʺ Drive T50 TORX Plus Male Socket 3/8ʺ drive (E11–E14), and 1/2ʺ drive
(E16–E24)
SPLINE SOCKETS
®
Snap-on spline wrenching tools have been developed to Chrome tools comply with Military Spec. MS-33787 and
service high tensile strength spline nuts and bolts widely MIL-W-8982. The unique spline wrenching configuration
used on both military and commercial aircraft. Precise, can also be used on ordinary six- and 12-point fasteners
®
radial spline teeth engage the fastener teeth over a wider with an advantage similar to the Snap-on Flank Drive
area to minimize stress, and allow application of high torque wrenching system.
to reduce risk of damage to the fastener or to the tool.
Shallow, Inches, Chrome (1/2ʺ)
Stock No. A B C D E
#16 1/2 SES161B 23/32 55/64 5/8 1-19/64 29/64
#18 9/16 SES181B 53/64 55/64 5/8 1-19/64 15/32
#20 5/8 SES201B 29/32 29/32 7/8 1-17/32 17/32
#22 11/16 SES221B 31/32 31/32 7/8 1-17/32 9/16
#24 3/4 SES241B 1-1/16 31/32 13/16 1-17/32 9/16
#26 13/16 SES261B 1-1/8 1-1/16 25/32 1-17/32 9/16
#28 7/8 SES281B 1-3/16 1-1/8 25/32 1-17/32 9/16
#30 15/16 SES301B 1-9/32 1-7/32 3/4 1-17/32 9/16
SES161B
229
• Do not use chrome or industrial finish hand tools with impact drivers
• Read safety precautions on pages W1 to W4
