SPARES KITS
SPARES KITS
8 NORTORQUE TORQUE WRENCHES 8 MULTIPLIER SPARES KIT
HANDLE KITS 16831 Spares Kit No� 2 Output Carrier
130501.060NLF Handle Repair Kit, 60 N·m/lbf·ft Scale 16836 Spares Kit No. 5 Output Carrier
130501�060NM Handle Repair Kit, 60 N·m Scale 16832 Spares Kit No� 7 Output Carrier
130501.100NLF Handle Repair Kit, 100 N·m/lbf·ft Scale 16835 Spares Kit No� 9 Output Carrier
130501�100NM Handle Repair Kit, 100 N·m Scale 19348 HT3-1000 N·m Retention Pin
130501.200NLF Handle Repair Kit, 200 N·m/lbf·ft Scale 19349 HT3-1000 N·m Cranked Reaction
130501�200NM Handle Repair Kit, 200 N·m Scale 19347 HT3-1000 N·m Straight Reaction
130501.300NLF Handle Repair Kit, 300 N·m/lbf·ft Scale 77018�1 Sq� Drive HT3 ∕ 4" (old style)
3
130501�300NM Handle Repair Kit, 300 N·m Scale 17185 Spares Kit HT3 ∕ 4" Sq Dr (Pre May 1993 style with shoulder
3
130501.340NLF Handle Repair Kit, 340 N·m/lbf·ft Scale screw)
130501�340NM Handle Repair Kit, 340 N·m Scale 17676 Sq� Drive HT3 ∕ 4"(to fit 17218, 17220 & all other models with
3
square drive retained by rollpin)
77018�1 17676 17185
13235 Repair Kit
8 NORTORQUE TORQUE WRENCHES 17223 Spares Kit HT3 Carriers
3
SQUARE DRIVE REPAIR KITS 17225 Spares Kit HT3 ∕ 4" Input Gear
13235 Sq� Dr� Repair Kit ∕ 8" (Mdl60) 18365 Spares Kit 72 mm Air Motor Handle
3
3
13236 Sq� Dr� Repair Kit ∕ 2" (Mdl100) 18544 Replacement ∕ 4" sq. dr., ET/EBT/PTS/PTM-52 Series
1
13237 Sq� Dr� Repair Kit ∕ 2" (Mdl200/300/340) 18545 Replacement 1" sq. dr., ET/EBT/PTS/PTM-52 Series
1
18779 Replacement ∕ 4" sq. dr., ET/EBT/PTS/PTM-72 Series
3
18492 Replacement 1" sq. dr., ET/EBT/PTS/PTM-72 Series
18221 Replacement ∕ 4" sq� dr�, PT 72 Series
3
18220 Replacement 1" sq� dr�, PT 72 Series
19260 Spares Kit for Fwd/Rev Gearbox Knob
post Feb 2011 Tools
19077 Upgrade Kit for Fwd/Rev Gearbox for PTM
8 ET/EBT/PTS/PTM-92 & ET/EBT/PTS/PTM-119
13212 Repair Kit SQUARE DRIVES
8 NORTORQUE TORQUE WRENCHES 18934 1" for ET/EBT/PTS/PTM-92
RATCHET REPAIR KITS 18935 1 ∕ 2" for ET/EBT/PTS/PTM-92
1
13212 Ratchet Repair Kit ∕ 8" (Mdl60) 18959 1 ∕ 2" for ET/EBT/PTS/PTM-119
3
1
13213 Ratchet Repair Kit ∕ 2" (Mdl100)
1
13214 Ratchet Repair Kit ∕ 2" (Mdl200) 8 VANE SETS FOR PNEUTORQUE MULTIPLIERS
1
13215 Ratchet Repair Kit ∕ 2" (Mdl300/340) 18631 For PTM Series (Pack of 5)
1
18278 For PT 72 mm Series (Pack of 6)
8 NORTORQUE TORQUE WRENCHES 16218 For PT Standard Series (Pack of 6)
OTHER REPAIR KITS
130500.K Locking Knob Kit
150103.K Thrust Washer and Screw Kit 8 SPARES FOR LUBRO CONTROL UNIT
28911 3 m Hose*
28912 6 m Hose*
28913 Pressure Gauge
28914 Filter Element for Filter/Regulator
28915 Bowl Assembly for Filter/Regulator
28916 Bowl Assembly for Lubricator
28917 Locking Collar
28918 1 ∕ 2" BSP Taper Thread Adaptor
*Other lengths of hose are available, please contact Norbar for details.
13215 Repair Kit
