CALIBRATION BEAMS & WEIGHTS

Calibration details
CALIBRATION BEAMS & WEIGHTS - IMPERIAL

Free
Model 100 mm 10" 12" 24" 48" Standing
Disc Beam Beam Beam Beam
Beam
Part Number 21400 21430 21424 21425 21426 21842
Minimum torque 0�44 10 10 50 100 300 lbf·ft
lbf·in lbf·in lbf·ft lbf·ft lbf·ft
9 IMPERIAL - POUNDS FEET SIZES Dimensions A 100 254 305 610 1,219 * 1,524
21400 25 lbf�in Torque Radius Disc (100 mm) (mm) B max. 295 650 690 965 1,015 1,070
21430 500 lbf�in Radius Ended Beam (10") Weight (kg) 0.5 1�2 3�7 17�3 26�4 270�0
21424 100 lbf�ft Radius Ended Beam (12") * A max. Torque Radius for 5,000 lbf·ft beam
21425 500 lbf�ft Radius Ended Beam (24")
21426 1,000 lbf�ft Radius Ended Beam (48")
21842 5,000 lbf�ft Free Standing Beam
With the exception of 21842 all calibration beams are supplied in
a protective case. A UKAS accredited calibration certificate for the
measurement of the torque radius is provided with each beam.

9 WEIGHTS FOR THE DISC 21400
21455�NAM Brass weight set to give 50 ozf�in (10 x 1.27 ozf)
21453�NAM Brass weight set to give 100 ozf�in (10 x 2.54 ozf)
21451�NAM Brass weight set to give 160 ozf�in (10 x 4.064 ozf)

9 WEIGHTS FOR THE BEAM 21430 Dimension A refers to Torque Radius of the beam, not length.
21465�NAM Cast iron weight set to give 100 lbf�in (10 x 1 lbf)
21466�NAM Cast iron weight set to give 500 lbf�in (10 x 5 lbf)
9 WEIGHTS FOR THE BEAM 21424
21467�NAM Cast iron weight set to give 100 lbf�ft (10 x 10 lbf)
9 ANCILLARY PRODUCTS FOR CALIBRATION BEAMS
9 WEIGHTS FOR THE BEAM 21425 J2676
21468�NAM Cast iron weight set to give 500 lbf�ft (10 x 25 lbf) 1,500 N.m Calibration Pedestal
J2329 Pro-Test Calibration Test Rig Assembly
80005 Adjustable Angle Attachment
9 WEIGHTS FOR THE BEAM 21426
21468�NAM Cast iron weight set to give 1,000 lbf�ft (10 x 25 lbf)
9 CALIBRATION FIXTURES
J5042.25 Transducer calibration fixture ∕ 4" sq
1
9 WEIGHTS FOR THE BEAM 21842 3
21469�NAM Cast iron weight set to give 5,000 lbf�ft (20 x 50 lbf) J5042.375 Transducer calibration fixture ∕ 8" sq
J5042.5 Transducer calibration fixture ∕ 2" sq
1
All weight sets come with a traceable UKAS accredited calibration J5042.75 Transducer calibration fixture ∕ 4" sq
3
certificate. This requires the customer to provide the value for 'g' (local
gravity) for the intended place of use when ordering. J5042.1 Transducer calibration fixture 1" sq
J3305 3° Angled Plate for use with calibration fixtures
