MarSurf WI 100

3D surface measurement

DESCRIPTION

Automatable, high-end measuring
system

The MarSurf WI 100 is a powerful
white light interferometer for the
three-dimensional measurement and
analysis of surfaces – contactless,
independent of material, and fast.
Allrounder-measurement solutions,
flexible at all times, exactly where it
comes down to the sub-nanometer:
this is what the new MarSurf WI
100 stand for. These high-precision
measurement tools for research and
quality assurance deliver reliable
3D measuring data – quickly and
straightforward in very few steps.
TECHNICAL DATA
With additional manual Z positioning,
a large x and y travel range and the WI 100
possibility of automation, it offers Measuring principle White Light Interferometer
excellent ease of use. The option of High-performance LED (650 nm / white)
performing user-independent, fully Resolution up to 0.2 (nm) vertical
automatic measurements makes this Measuring speed up to 140 fps
surface measuring system ideal for Surface parameters ISO 4287, ISO 13565, ISO 25178 …
straightforward and efficient use in
quality assurance.

Key benefits:
• User-independent serial measure-
ments by automation software
• High measuring speed – even at Supplied with: APPLICATION:
full resolution MarSurf WI 100
• User-friendly concept • Interferometric measuring head • Mechanical Engineering
• Safety through collision detection – HDR camera (2 MP or 5 MP) To qualify and quantify roughness, geometry and wear volume
in all directions to protect your – 4x lens revolver with identification
workpiece and measuring system L-tripod including control • Electronics and semiconductors
• High Dynamic Range (HDR) electronics Component inspection down to the sub-micrometer range for
function, 16-bit • Motorized XY table (100 x 100 mm) defect-free products
• HD-stitching: Consistent high with glass scales for sample
resolution output of large positioning and image field • Medical Technology
measuring surfaces merging (“stitching”) Quality assurance of medical surfaces in production and laboratory
• Motorized Z-axis (70 mm) with
This established optical measuring glass measuring scale • Material Science
system is successfully used, for • Additional manual Z-Axis (100 mm) Optimization of functional properties of new surfaces and products
example, for: • Measuring system computer with
• Roughness measurement according 24”-TFT-monitor • Microsystems Technology
to DIN EN ISO 4287 / 25178 • Objective lenses: Measure complex surface geometries of smallest components with
• Topography measurement – 2.5x to 100x selectable nanometer precision
(including volume, wear, isotropy) • MarSurf MSW for intuitive data
• Measurement of microgeometry acquisition
and layer thicknesses • MarSurf ASW for automation
Users value the reliability of this (optional)
measuring system, which provides • MarSurf MfM for professional
quantitative, traceable 3D evaluation, graphical representation
characteristics for many industries and creation of measuring records
(choice of Standard, Extended or
Premium version)

For more information, please visit our website: www.mahr.com
