WORKSHOP TOOLS

Universal Bearing Puller Set

9BA33

• Easy and fast removing ball bearing by using the puller
• Select proper tips by ball diameter
CONTENTS :
• 1 PC. Puller yoke M14 x2.0 and 16
center screw Hex 21mm x280mmL PC.
• 1 PC. Top Nut
• 2 PC. Extension rod x L 170mm
Ball ended threaded adapter :
• 2 PC. 15.0mm / 2 PC. 17.4mm
• 2 PC. 20.0mm / 2 PC. 25.2mm
• 2 PC. 30.0mm / 2 PC. 36.4mm
kg 8.00 1 / 3

90°

Slide Hammer Gear Puller Set

796401MR
Slide Hammer Puller Set CONTENTS:
• For jobs involving pull and grip gears, bearings, • 1 PC. 400 mm T handle shaft
outer races, grease retainers, oil seals, etc. • 1 PC. 2.6 Ibs / 1.2 kgs hammer
• 2.6 lbs(1.2 kgs) slide hammer • 1 PC. Adjustable nut
• 400 mm length T-handle puller • 1SET Internal gear puller for Ø15-30mm(A)
• 1SET Internal gear puller for Ø30-80mm(B)
• 3-in-1 hammer puller, to handle inside pull such as • 1SET External gear puller for Ø15-80mm(C) 6
bearing cups and outer races, as well as regular PC.
outside pull jobs

kg 4.50 1/4
D
Items (mm) Capacity
Internal gear puller 6 Ø 15-30mm
Internal gear puller 10.5 Ø 30-80mm
External gear puller 10.5 Ø 15-80mm

474
