Half Moon Ring Wrench & Set

1950

• Short pattern design enables greater access in confined spaces
• Chrome vanadium alloy steel
• Chrome plated
• DIN 3113
S1 S2
H
D2
H1 H2
L
H2
H1
L
D2
D1
H
KT NO. Size mm mm mm mm mm mm g
mm
19500810 8 x 10 15.6 14.3 137 6.5 6.2 42 40 12 / 288
19501012 10 x 12 15.6 18.2 141 6.6 6.5 50 61 12 / 288
19501113 11 x 13 18.2 21.0 166 8.2 8.0 63 101 8 / 128
19501214 12 x 14 18.2 21.0 166 8.2 8.0 63 95 8 / 128
19501315 13 x 15 22.0 25.0 190 9.2 8.2 75 133 6 / 72
19501417 14 x 17 22.0 25.0 190 9.2 8.2 75 130 6 / 72
19501618 16 x 18 25.5 28.0 220 9.6 8.8 79 164 6 / 72
19501719 17 x 19 25.5 28.0 220 9.6 8.8 79 163 6 / 72
19501922 19 x 22 28.6 32.5 256 11.1 10.1 91 257 6 / 48
KT NO. PC. Contents Kg
9-1905MR 5 10 x 12, 11 x 13, 14 x 17, 16 x 18, 19 x 22 0.82 1 / 10
1950

Crowfoot Wrench & Set

1031

• 12 points L
• For union nuts and tube connections
• With square mount D

T
Lw
T
L
D
Drive
Lw
KT NO. Size square mm mm mm mm g
mm
1031-10R 10 3/8" 27.0 9.2 36.5 17.1 40 12 / 192
1031-11R 11 3/8" 27.0 9.2 36.5 17.0 40 12 / 192
1031-12R 12 3/8" 27.5 9.2 36.5 16.8 40 12 / 192 • Use to reach limit place with extension bar
1031-13R 13 3/8" 27.2 9.3 36.5 16.7 40 12 / 192 • Use with torque wrench and 90 ° extension bar, will not effectively
1031-14R 14 3/8" 29.8 9.6 42.0 20.0 42 12 / 192 change the torque value
1031-15R 15 3/8" 31.4 9.2 42.0 19.2 44 12 / 192
1031-16R 16 3/8" 30.2 10.1 42.0 19.5 48 12 / 192 KT NO. Size Drive D T L Lw g
mm square mm mm mm mm
1031-17R 17 3/8" 34.0 11.4 45.6 23.5 68 12 / 192
1031-18R 18 3/8" 33.6 10.0 45.6 22.5 63 12 / 192 1031-34R 34 3/4" 55.6 22.5 84.5 38.0 345 12 / 60
1031-19R 19 3/8" 33.7 10.8 45.8 23.0 63 12 / 192 1031-35R 35 3/4" 55.6 22.5 84.5 39.0 334 12 / 60
1031-22R 22 1/2" 38.5 13.0 55.0 23.0 82 15 / 180 1031-36R 36 3/4" 55.6 22.5 84.5 39.0 315 12 / 60
1031-24R 24 1/2" 38.5 12.5 55.0 24.5 74 15 / 180 1031-38R 38 3/4" 61.7 23.0 90.5 43.0 346 12 / 60
1031-26R 26 1/2" 42.5 13.5 60.0 24.0 105 15 / 180 1031-41R 41 3/4" 61.7 23.0 90.5 43.0 357 12 / 60
1031-27R 27 1/2" 42.5 13.5 61.0 25.0 98 15 / 180 1031-46R 46 3/4" 70.0 25.0 101 47.0 517 12 / 24
1031-30R 30 1/2" 49.0 14.0 68.5 30.0 136 12 / 144 1031-48R 48 3/4" 75.5 28.5 104 47.0 482 12 / 24
1031-32R 32 1/2" 50.0 14.0 70.0 30.0 136 12 / 144 1031-50R 50 3/4" 75.5 28.5 104 48.0 587 12 / 24

KT NO. PC. Contents Kg
1E10MR 10 10, 11, 12, 13, 14, 15, 16, 17, 18, 19 0.59 1 / 30

1E11MR 11 1031 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 22 0.68 1 / 30
