Star Socket KT No. & D1
3375M 3/8"
• DIN 3120
D1 D2
l L
D2
D1
ℓ
L
KT NO. Size mm mm mm mm g
337504M E4 6.0 16.8 3.6 28 21 12 / 360
337505M E5 7.0 16.8 4.0 28 21 12 / 360
337506M E6 8.0 16.8 5.0 28 22 12 / 360
337507M E7 8.9 16.8 6.0 28 22 12 / 360
337508M E8 10.0 16.8 6.5 28 23 12 / 360
337510M E10 12.0 16.8 7.0 28 24 12 / 360
337511M E11 12.8 16.8 8.0 28 24 12 / 360
337512M E12 14.3 16.8 9.0 28 26 12 / 360
337514M E14 15.9 17.8 9.5 28 31 12 / 360
337516M E16 18.0 19.8 10.5 28 42 10 / 300
337518M E18 20.0 21.8 11.0 28 55 10 / 300
3275M 3/8"
• DIN 3120
D1 D2
l L
L
D2
D1
ℓ
KT NO. Size mm mm mm mm g
327504M E4 6.0 16.8 3.6 63 45 12 / 240
327505M E5 7.0 16.8 4.0 63 47 12 / 240
327506M E6 8.0 16.8 5.0 63 48 12 / 240
327507M E7 8.9 16.8 6.0 63 49 12 / 240
327508M E8 10.0 16.8 6.5 63 52 12 / 240
327510M E10 12.0 16.8 7.0 63 57 12 / 240
327511M E11 12.8 16.8 8.0 63 59 12 / 240
327512M E12 14.3 16.8 9.0 63 65 12 / 240
327514M E14 15.9 16.8 9.5 63 67 12 / 240
327516M E16 17.8 17.8 10.5 63 77 12 / 240
327518M E18 19.8 19.8 11.0 63 100 10 / 160
333E 3/8"
• For torx plus external screw
• DIN 3120
D1 D2
l L
D1
D2
L
ℓ
KT NO. Size mm mm mm mm g
333E10M EP10 13.2 10.5 8 37 53 20 / 240
333E11M EP11 14.0 11.0 9 37 53 20 / 240
333E12M EP12 14.6 12.0 10 37 53 20 / 240
333E14M EP14 16.5 14.0 11 37 55 20 / 240
333E16M EP16 19.0 16.0 12 37 59 20 / 240
333E18M EP18 20.3 18.0 15 37 60 20 / 240
333E20M EP20 21.8 19.5 15 37 63 20 / 240
