Page 271 - HAZET英文2021

Torque Technology Torque Technology

Insert torque wrenches

Universal in scope – with the best intentions No need

The use of over 100 insert tools allows any challenge to be mastered! to turn
back!

SYSTEM 5200-3 CT

• Torque ranges: 10 – 200 Nm
• Accuracy ± 3% of scale value
• Tested in accordance with DIN EN ISO 6789-2:2017
• With calibration certificate and serial number
• Handle of the 5000-3 CT series
– Detent point for rapid adjustment of the torque value
– Can be attached to the cable loop
• Insert square B or D to hold insert tools

SYSTEM 6200-1 CT

• Torque ranges: 2 – 500 Nm
• Accuracy ± 2% of scale value
• Tested in accordance with DIN EN ISO 6789-2:2017
• With calibration certificate and serial number
• All advantages of the 6000 CT series
• Insert square B or D to hold insert tools

SYSTEM 6300

• With permanently adjustable value – especially suitable
for application in industrial series production
• Without setting scale and signal transmitter
• Repeat accuracy after 5,000 tightening
operations ± 2 % (6391-10 ± 6 %)
• Automatic close-gap release – reaching the set
value is signaled palpably and audibly
• Torque function only for right-hand thread
• Adjusting the desired torque value with adjustment wrench 6399
together with torque tester – e.g. HAZET 7901 E, 7902 E or 7903 E
Unauthorised adjustment is thereby prevented
• Torque ranges: 1 – 320 Nm
• Tested in accordance with DIN EN ISO 6789-2:2017
• With calibration certificate and serial number
• Insert square B or D to hold insert tools

Made in Germany
270 Valid until December 31, 2021 Components and spare parts from page 482 to 490
