Filler piece Shearbolt terminals 10 - 630 mm² (reversible screw)
To splice the copper screen around the conductors, a filler piece is
required that is placed between the screw and the screen. To select Properties:
the correct filler piece, see table. Requires 2 filler pieces per splice. • screw material: brass for minimum friction
• reversible shear-off screws
• voltage range: 1 kV to 36 kV
• meets the requirements of standard IEC 61238-1
• the terminals are of the bimetallic type for best functionality
SC95N PEN
Name Screen conductor Note
SC95N/PEN 16-57* *16-50 mm² (SC95N) / 16-57 mm² (SC95R95S)
SC150N/PEN 21-95
SC240/PEN 29-146 Shearbolt terminal
Shearbolt terminals 10 - 630 mm² (pre-assembled screw) Cable type Cable type Screen W
round mm² sector mm² Name conductor Screw mm d D N cc a L L1
Properties: 10-70 25-70 SL70R70S-10-12 10-57 M10, M12 25,5 11,0 21 12,5 12 97 59
• screw material: brass for minimum friction 95-150 95 SL150R95S-10-12 70-95 M10, M12 26 16 27 12,5 12 116 75,5
• pre-assembled shear-off screws for easy handling 95-150 95 SL150R95S-12X2-40 70-95 M12x2 30,5 16 27 15 40 12 172 75,5
• voltage range: 1 kV for SL50N-10-12, SL95N-10-12 185-240 120-185 SL240R185S-12-16 M12, M16 31,5 20 33,5 15 16 134 78,5
and SL240N-10-12, 1-36 kV for the others 300-400 240 SL400R240S-16 M16 41,5 25,8 41,5 21 16 182 103
• meets the requirements of standard IEC 61238-1 300-400 240 SL400R240S-20 M20 41,5 25,8 41,5 21 20 182 103
• the terminals are of the bimetallic type 300-400 240 SL400R240S-00 41,5 33 49 187 103
500-630 SL500B-630B-12X2-40 M12x2 55 33 49 12 40 12 218 115
500-630 SL630R-1 55 33 49 243 129
500-630 SL630R-16 M16 55 33 49 30 16 241,5 129 08
500-630 SL630R-14 M14 55 33 49 30 14 243 129
500-630 SL630R-12X2-40 M12x2 55 33 49 15 40 12 243 129
t = palm thickness, s = strip length
Screw branch clamps
Screw clamps for earthing applications. Enables branching of reinforcing
bars with a stranded earth line in Cu or Fe.
Name Pcs/pack
SBC50 1
Cable type Cable type Name Screen Screen conductor Screw W d D N cc a L L1 t s
round mm² sector mm² conductor (with filling piece) mm
10-50 10-50 SL50N-10-12 10-35 M10, M12 25,5 12 20/17,3 12,5 13 87 44 5,9 32
35-95 35-95 SL95N-10-12 57-95 16-50 (SC95N/PEN) M12, M10 27,3 16 17/23 12,5 13 96 52,5 4,7 56
120-240 120-240 SL240N-10-12 29-146 (SC240/PEN) M12, M10 31,5 25 38/33,1 15 13 144,586 7,6 76 Counterhold tool
185-240 SL240R-12-16 M12, M16 30 20 33,5 15 12 134 79 7,9 75
185-240 SL240R-12X2-40 M12x2 31,5 20,0 33,5 15 40 12 174 79 7,9 75
300-400 SL400R-12X2-40 M12x2 42 25,8 41,5 15 40 12 210 103 9,6 99 Counterhold tool for stable and safe installation of shearbolt terminals. Tools are made from
630 SL630B-12X2-40 M12x2 55 33,0 49,0 17 40 12 218 115 11,7 108 durable material and are easily adjustable for terminals up to 400 mm².
t = palm thickness, s = strip length
Name Pcs/pack
ISL2201 1
ISL2201
