PS710E

For fitters working in the distribution network or industry.

Properties:
• small and light weight, which makes the product easy to use in every situation
• maximum performance, can be used both with Li-ion battery 28.8 V or 220V
mains power
• LCD Display with keypad for full status information of pump to the fitter
• able to store and document crimps in the control system
• PC communication via USB
• to be used with crimp heads and cable cutters
• Elpress ergonomic handle ERGOCOM, with wireless communication can be
selected for
• charger 230 VAC 50 Hz, 10.8-28.8 V, charging time 65 min

Net weight Length
Name Width Height
(kg) mm
PS710E 12 370 170 280
Pump PS710E

06
PS710E251 and PS710E501*

Contains:
• pump E-version
• cable
• hydraulic hose 2.4 m or 5.0 m with wireless communication ERGOCOM
• battery
• charger
• carrying strap
• 110-240VAC 50-60Hz

Gross Length
Name Width Height Note
weight (kg) mm
PS710E251 24,5 370 170 280 PS710E pump with carrying strap.
Ergocom hose 2.4 m and power
cord EU, battery and charger
PS710E501 26,0 370 170 280 PS710E pump with carrying strap.
Ergocom hose 5.0 m and power
cord EU, battery and charger
PS710E501-US 26,0 370 170 280 PS710E pump with carrying strap.
Ergo hose 5.0 m and power cord
US, battery and charger
PS710E251-US 24,5 370 170 280 PS710E pump with carrying strap.
Ergo hose 2.4 m and power cord
US, battery and charger
ERGOCOM hoses are not available in US/North American market.
