P. 285
STANDARD
PLUS
STANDARD
PROFESSIONAL
PROFESSIONAL
PLUS
PROFESSIONAL PLUS STANDARD
Push-through ratchet with rough toothing
Art.-Group 190
▶ Robust and durable ratchet mechanism L1
▶ With robust rough toothing mechanism (48 teeth) for highest loads L2
▶ Switching from right-hand to left-hand happens when turning the ratchet
▶ Ratchet with ergonomic 2-component handle for secure support and A1 A2
fatigue-free work
B1 B2
Equipping Push-through square Handle 2-components-plastic
Material Chrome-vanadium steel Output Various
Coating Chrome-plated and matt-satin finish Output locking Ball catch groove, ball lock
Application Type Manually operated Norm DIN 3122 / ISO 3315 / DIN 3120 / ISO 1174
Without packaging
Size Description Toothing max. torque Nm L1 mm L2 mm A1 mm A2 mm B1 mm B2 mm €/Pc. Art.-No.
12.5 [1/2“] Reversible ratchet 12.5 [1/2“] Rough, 48 teeth 600 251 105 35.5 28.0 39.0 35.0 34.24 4297
12.5 [1/2“] Push-through square 12.5 [1/2“] 34 6.67 429 7-1
PLUS
STANDARD
PROFESSIONAL PLUS STANDARD
PROFESSIONAL
PLUS
STANDARD
PROFESSIONAL
Radiator spud wrench for push-through ratchet
Art.-Group 190
▶ Radiator spud wrench allows fitting and removal of radiator-fittings,
return-fittings and short plug valves
Material Chrome-vanadium steel Drive Outside square according to DIN 3120 / ISO 1174
Coating Chrome-plated and matt-satin finish Locking Drive Ball stop
Application Type Manually operated Norm DIN 3120 / ISO 1174
Description €/Pc. Art.-No.
Radiator spud wrench 5-steps 9.5 [3/8“] - 11.5 [29/64“] - 12.3 [31/64“] - 16.7 [21/32“] - 21 [53/64“] 23.43 429 7-2
Radiator spud wrench 8-steps 9.5 [3/8“] - 11.1 [7/16“] - 11.9 [15/32“] - 12.7 [1/2“] - 13.9 [35/64“] - 19 [3/4“] - 21.4 [27/32“] - 22.2 [7/8“] 30.81 429 7-3
STANDARD
PLUS
STANDARD
PROFESSIONAL PLUS STANDARD
PROFESSIONAL
PROFESSIONAL
PLUS
Push-through ratchet set with radiator spud wrench
3 Art.-Group 190
PIECES
▶ Robust and durable ratchet mechanism
▶ With robust rough toothing mechanism (48 teeth) for
highest loads
▶ Switching from right-hand to left-hand happens when
turning the ratchet
▶ Ratchet with ergonomic 2-component handle for secure
support and fatigue-free work
▶ Radiator spud wrench allows fitting and removal of
radiator-fittings, return-fittings and short plug valves
Equipping Push-through square Application Type Manually operated
Material Chrome-vanadium steel Output Outside square according to DIN 3120 / ISO 1174
Coating Chrome-plated and matt-satin finish Output locking Ball stop
Handle 2-components-plastic Norm DIN 3122 / ISO 3315 / DIN 3120 / ISO 1174
Euro pocket
Content €/Pc. Art.-No.
1 Push-through ratchet 12.5 [1/2“] (4297)
1 Push-through square 12.5 [1/2“] (4297-1) 54.79 4 297 -10
1 radiator spud wrench 5-steps 9.5 [3/8“] - 11.5 [29/64“] - 12.3 [31/64“] - 16.7 [21/32“] - 21 [53/64“] (4297-2)
H 283
