PROFESSIONAL PLUS STANDARD PROFESSIONAL PLUS STANDARD
Tube cutter with deburrer Tube cutter QUICK with
for tubes Ø 3 - 45 mm deburrer for tubes Ø 6 - 76 mm

Art.-Group 190 Art.-Group 190
▶ Ideal for thin metal tubes ▶ Ideal for thin metal tubes
▶ Steel bearing arbor for better sliding of the carriage ▶ Quick-adjusting system reduces the processing time
▶ With 4 rollers for a better fastening of the tube ▶ Steel bearing arbor for better sliding of the carriage
▶ With completely removable NOGA reamer ▶ With 4 rollers for a better fastening of the tube
▶ Quick and tool-free change of the cutting wheel ▶ With completely removable NOGA reamer
▶ Including spare wheel in the rotary knob ▶ Quick and tool-free change of the cutting wheel
▶ Ergonomic rotary knob ▶ Including spare wheel in the rotary knob
▶ Ergonomic rotary knob
Application For cutting aluminum, copper and thin steel tubes Application For cutting aluminum, copper and thin steel tubes
For tubes Ø 3 - 45 mm For tubes Ø 6 - 76 mm
Maximum wall thickness 2 mm Maximum wall thickness 2 mm
LxWxH 70 x 50 x 25 mm LxWxH 255 x 100 x 30 mm

Cardboard card with hanger Cardboard card with hanger
Description €/Pc. Art.-No. Description €/Pc. Art.-No.
Tube cutter 48.16 396 213 Tube cutter 107.06 396 214
Spare wheel 19 x 5 for Al, Cu, stainless steel 5.81 6299-01 Spare wheel 19 x 6.2 for Al, Cu, stainless steel 6.34 6 299-05
Spare wheel 22 x 5 for plastic 8.48 6299-07 Spare shaft for cutting wheel 3.64 6299-08
Spare shaft for cutting wheel 3.54 6299-03
Spare deburrer 7.90 6299-09

PROFESSIONAL PLUS STANDARD PROFESSIONAL PLUS STANDARD
Tube cutter PT QUICK Tube cutter
for tubes Ø 6 - 76 mm for tubes Ø 10 - 60 mm

Art.-Group 190 Art.-Group 190
▶ Ideal for plastic and composite tubes ▶ Ideal for steel and stainless steel tubes
▶ Steel bearing arbor for better sliding of the carriage ▶ Robust drop forged steel frame for a long lifetime
▶ With 4 rollers for a better fastening of the tube ▶ Spring system guarantees a better cutting result and a
▶ Quick-adjusting system reduces the processing time longer lifetime of the cutting wheels
▶ With completely removable NOGA reamer ▶ Quick and tool-free change of the cutting wheel
▶ Quick and tool-free change of the cutting wheel
▶ Including spare wheel in the rotary knob
▶ Ergonomic rotary knob
Application For cutting plastic and composite tubes Application For cutting steel and stainless steel tubes
For tubes Ø 6 - 76 mm For tubes Ø 10 - 60 mm
Maximum wall thickness 2 mm Maximum wall thickness 2 mm
LxWxH 255 x 100 x 30 mm LxWxH 385 x 110 x 50 mm

Cardboard card with hanger Paper box
Description €/Pc. Art.-No. Description €/Pc. Art.-No.
Tube cutter 93.43 396 215 Tube cutter 97.06 6216
Spare wheel 26 x 6.2 for plastic and composite Spare wheel 31 x 19 for steel and stainless steel 12.64 6 299-02
tubes 10.83 396299-06 Spare shaft for cutting wheel 4.85 6 299-04
Spare shaft for cutting wheel 3.64 6299-08

H 279
