PROFESSIONAL PLUS STANDARD PROFESSIONAL PLUS STANDARD
Small tube cutter for stainless Tube cutter with deburrer for
steel tubes Ø 3 - 30 mm stainless steel tubes Ø 3 - 35 mm

Art.-Group 190 Art.-Group 190
▶ Ideal for cutting thin stainless steel tubes ▶ Ideal for cutting thin stainless steel tubes
▶ Rollers and cutting wheel with needle bearings and special ▶ Rollers and cutting wheel with needle bearings and special
edge geometry for stainless steel tubes edge geometry for stainless steel tubes
▶ Also suitable for all other types of metal tubes ▶ Also suitable for all other types of metal tubes
▶ Steel bearing arbor for better sliding of the carriage ▶ Steel bearing arbor for better sliding of the carriage
▶ Quick and tool-free change of the cutting wheel ▶ With 4 rollers for a better fastening of the tube
▶ Including spare wheel in the rotary knob ▶ With completely removable NOGA reamer
▶ Extremely reduced spin radius due to the compact tube ▶ Quick and tool-free change of the cutting wheel
cutter ▶ Including spare wheel in the rotary knob
▶ Ergonomic rotary knob ▶ Ergonomic rotary knob
Application For cutting especially stainless steel, but also for Application For cutting especially stainless steel, but also for
aluminum, copper and thin steel tubes aluminum, copper and thin steel tubes
For tubes Ø 3 - 30 mm For tubes Ø 3 - 35 mm
Maximum wall thickness 2.5 mm Maximum wall thickness 2.5 mm
LxWxH 70 x 50 x 25 mm LxWxH 160 x 40 x 60 mm

Cardboard card with hanger Cardboard card with hanger
Description €/Pc. Art.-No. Description €/Pc. Art.-No.
Tube cutter 32.12 396 221 Tube cutter 47.81 396 222
Spare wheel 19 x 5 for stainless steel 5.99 396297-01 Spare wheel 19 x 5 for stainless steel 5.99 396297-01

PROFESSIONAL PLUS STANDARD PROFESSIONAL PLUS STANDARD
Tube cutter with deburrer for Tube cutter QUICK for
stainless steel tubes Ø 3 - 45 mm stainless steel Ø 6 - 76 mm

Art.-Group 190 Art.-Group 190
▶ Ideal for cutting thin stainless steel tubes ▶ Ideal for cutting thin stainless steel tubes
▶ Rollers and cutting wheel with needle bearings and special ▶ Rollers and cutting wheel with needle bearings and special
edge geometry for stainless steel tubes edge geometry for stainless steel tubes
▶ Also suitable for all other types of metal tubes ▶ Also suitable for all other types of metal tubes
▶ Steel bearing arbor for better sliding of the carriage ▶ Steel bearing arbor for better sliding of the carriage
▶ With 4 rollers for a better fastening of the tube ▶ With 4 rollers for a better fastening of the tube
▶ With completely removable NOGA reamer ▶ Fast feed system reduces the processing time
▶ Quick and tool-free change of the cutting wheel ▶ With completely removable NOGA reamer
▶ Including spare wheel in the rotary knob ▶ Quick and tool-free change of the cutting wheel
▶ Ergonomic rotary knob ▶ Including spare wheel in the rotary knob
▶ Ergonomic rotary knob
Application For cutting especially stainless steel, but also for Application For cutting especially stainless steel, but also for
aluminum, copper and thin steel tubes aluminum, copper and thin steel tubes
For tubes Ø 3 - 45 mm For tubes Ø 6 - 76 mm
Maximum wall thickness 2.5 mm Maximum wall thickness 2.5 mm
LxWxH 180 x 40 x 70 mm LxWxH 255 x 100 x 30 mm

Cardboard card with hanger Cardboard card with hanger
Description €/Pc. Art.-No. Description €/Pc. Art.-No.
Tube cutter 66.81 396 223 Tube cutter 115.29 396 224
Spare wheel 19 x 5 for stainless steel 5.99 396297-01 Replacement wheel 19 x 6.2 for V2A / INOX 6.11 396297-05

H 281
