For safety use, read following instructions carefully before using tools.

)FYBHPO XSFODI LJOET GPS NBOVBM
WARNING

˔ Plastic handle does not mean tools are insulated.

HEXAGON WRENCH
˔ Use right size O-ring and pin and fix them securely.

˔ O-ring and pin are expendable. Replace these parts fig.1
immediately when crack, wear or distortion is found. (fig.1)

CAUTION

˔ Do not use tool for purposes not intended.

˔ Hex socket set screws have smaller hex hole than bolt diameter,

which means that hex wrenches receive higher load.

˔ Do not use galvanized hand tools with power tools like impact fig.2
wrench. (fig.2)

˔ Use right size hex wrench fitting in hex socket set screws. If the
hex wrench is smaller it slips in the hole. Also avoid using metric
size hex wrench for inch size bolts.

˔ When using hex wrenches, remove the gap complerely between fig.3
the tip of hex wrench and hex socket set screw. If the installation
is incomplete and excessive force is applied hex wrench can be
disconnected and might cause injury. (fig.3)

)FYBHPO TPDLFU LJOET GPS JNQBDU
WARNING

˔ Do not touch rotating socket or joint. (fig.4)
fig.4

1MFBTF TFF UIF DPOUFOUT PG B IFYBHPO XSFODI GPS UIF BCPWF NBOVBM BOE 1
