T-shaped
T-TYPE HEXAGON WRENCH The total length is long, it is most suitable for work in narrow and
deep places.
T-handle type allows strong tightening.
Across Dimensions (mm) Qty./Carton Weight
Models Flat Type
(mm) D L1 H L (Generally) (Store Center) (g)
THW-2.5 2.5 9.0 22 100 150 Ⅰ 5 5 115
THW-03 3 9.0 25 100 160 Ⅰ 5 5 120
THW-04 4 9.0 30 120 200 Ⅰ 5 5 140
THW-05 5 11.0 40 160 250 Ⅰ 5 5 270
THW-06 6 12.7 45 190 300 Ⅰ 5 5 440
THW-08 8 12.7 16 190 300 Ⅱ 5 5 450
THW-10 10 12.7 20 190 300 Ⅱ 5 5 460 THW-05
THW-12 12 14.0 24 210 320 Ⅱ 5 5 610
THW-14 14 16.0 28 220 340 Ⅱ 5 5 840
THW-17 17 20.0 34 220 340 Ⅱ 5 5 1,310 THW-12

5ZQF I 5ZQF II

5ZQF I 5ZQF II

ɹ 5)8 ɹ 5)8
ʙ
ʙ
5)8 5)8

LONG T-TYPE HEXAGON WRENCH T-shaped hexagon wrench has a total length of 500 mm! !
Suitable for working in deep places.

Across Dimensions (mm) Qty./Carton Weight
Models Flat Type
(mm) (g)
D L1 H L (Generally) (Store Center)
THW-04L500 4 9.0 30 120 500 Ⅰ 1 1 290
THW-05L500 5 11.0 40 160 500 Ⅰ 1 1 460
THW-06L500 6 12.7 45 190 500 Ⅰ 1 1 640
THW-08L500 8 12.7 45 190 500 Ⅱ 1 1 650
THW-10L500 10 12.7 50 190 500 Ⅱ 1 1 660
5ZQF I 5ZQF II

THW-05L500

5ZQF I 5ZQF II
THW-08L500

5)8 -
5)8 - 5)8 -
ɹ
ɹ

5)8 - 5)8 -

301
