ST2P
ST-P ・ ST T-P Stopper ST2 Stopper

■ SUPER TONG, Chain Pipe Wrench ST ・ ST-L
Replaceable Heel Jaw Type ■ SUPER TONG, Chain Pipe Wrench
PIPING TOOLS
(Heavy Duty Type for Professional Use) (Heavy Duty Type for Professional Use)
Features Features
● As a replaceable heel jaw teeth type, when the jaw ● Optimal for work in narrow places where pipe wrench
teeth get worn, it can be replaced, so the tool can be cannot be used.
used for a long time. ● Can work repeatedly with one-time setting (not for
● Optimal for work in narrow places where pipe wrench coated steel pipe).
cannot be used. ● For ST3, 3L and 4 it is possible to add pipes (sold
Tube ● Can work repeatedly with one-time setting (not for separately) to the handle.
cutters
coated steel pipe).
Applicable pipe Body full length N.W. Applicable pipe Body full N.W.
Item No. Item No.
Size name External dia.（mm） (mm) （kg） Size name External dia.（mm） length (mm) （kg）
Other
cutters ST1.5P 10A〜100A 17〜120 425 1.8 ST0 8A〜40A 12〜50 230 0.3
ST2P 20A〜150A 25〜170 510 2.6 ST1 8A〜80A 14〜89 305 0.8
ST2.5P 25A〜200A 34〜230 695 5.3 ST1L 8A〜150A 14〜170 305 1.1
Pipe scrapers,
super torque Stopper to prevent the chain from coming off included. ST1.5 10A〜100A 17〜120 425 1.8
wrenches Chain links can be added up to twice the original chain length.
ST2 20A〜150A 25〜170 510 2.6
ST2L 20A〜200A 25〜230 510 3.1
ST2.5 25A〜200A 34〜230 695 5.3
Flaring tools
■ Heel Jaw Teeth (hex. socket
head screw included) ST3 25A〜250A 35〜270 745 6.3
ST3L 25A〜300A 35〜320 745 6.6
Item No. Applicable item
Flanging ST4 50A〜500A 60〜510 745 10.5
tools for
flexible tube STT1.5P ST1.5P For ST1.5 and above, stopper to prevent the chain from coming
STT2P ST2P off included.
Replaced heel Chain links can be added up to twice the original chain length
STT2P jaw teeth STT2.5P ST2.5P (except for ST1L, 2L and 3L).
STC ・ STC-L ・ STP ・ STH
Benders
■ SUPER TONG Parts
Chain pipe
wrenches
L ■ Pin
connecting pin swaging pin
Item
Pipe T T1 No. Applicable item
wrenches,
belt STC1 L1 L1 STP0 ST0
wrenches
STP1 ST1・1L
STP1.5 ST1.5・1.5P
Motor ■ Chain (body fixing pin included)
wrenches, STP2 ST2・2L・2P
other Total Number Number of
wrenches Item L L1 number of of swaging links linked to T T1
No. （mm） （mm） links pins swaging pins （mm）（mm） STP2.5 ST2.5・2.5P
STC0 243 14.3（9/16） 17 4 5 14 7.2 STP2 STP3 ST3・3L
Water pump STC1 438 19（3/4） 23 4 5 20 9.6 STP4 ST4
pliers
STC1L 667 19（3/4） 35 4 5 20 9.6
STC1.5 514 19（3/4） 27 4 5 20 9.6
Super pilers, STC2 685 25.4（1） 27 6 7 28 12.8 STH3 ＊ Only for ST3, 3L and 4.
threaded
rod cutters STC2L 838 25.4（1） 33 6 7 28 12.8 ■ Pipe (to connect to the body)
STC2.5 857 31.8（11/4） 27 6 7 40 16 Applicable Size （mm） N.W.
Item No.
STC3 984 31.8（11/4） 31 6 7 40 16 item Full length External dia. Pipe thickness （kg）
Plumbing
tool set STC3L 1,111 31.8（11/4） 35 6 7 40 16 STH3 ST3・3L 1,000 43 5 4.5
STC4 1,867 38.1（11/2） 49 6 7 50 19.2 STH4 ST4 1,500 45 5 7.5

96 ●For all the appendix of the piping tools, please refer to P.283
