TS456(WQH ・ WH ・ WRH ・ WDH)

■ TUBING TOOL SET
(Eccentric Cone Type)

Adapted to new standard / new cooling media
Features
TS456WQH TS456WH
(quick handle type) PAT. (feed handle type) ● Set for cutting, chamfering and flaring.
● Adapted to annealed copper pipe 3/4’’, thickness 1.2mm. PIPING TOOLS
● Steel case as standard acc.

TS456WRH TS456WDH
(ratchet handle type) (manual / electric type)
Copper pipe applicable diameter (size name) Set N.W.
Item No. Set details
(copper pipe for general cooling media piping) （kg） Tube
cutters
TS456WQH TF456WQH・TC105・TR322 4
TS456WH TF456WH・TC105・TR322 3.8
1/4 ・ 5/16 ・ 3/8 ・ 1/2 ・ 5/8 ・ 3/4
TS456WRH TF456WRH・TC105・TR322 4.1
Other
TS456WDH TF456WDH・TC105・TR322 3.9 cutters
TFG-N Pipe scrapers,
super torque
■ GAUGE BAR wrenches

Adapted to new cooling media Flaring tools
■ Applicable models
Eccentric Cone Type Flaring Tools all models
(except TFA455WH, TF459W, TF459M).
Flanging
tools for
flexible tube

TFG456N
Benders

Copper pipe applicable diameter (size name) N.W.
Item No. Number of holes
(copper pipe for general cooling media piping) （g）
Chain pipe
TFG455N 5 1/4 ・ 3/8 ・ 1/2 ・ 5/8 ・ 3/4 530 wrenches
TFG456N 6 1/4 ・ 5/16 ・ 3/8 ・ 1/2 ・ 5/8 ・ 3/4 570
Pipe
wrenches,
TFAG455N wrenches
belt
■ GAUGE BAR Aluminum Alloy Body Motor
wrenches,
other
wrenches
■ Applicable model
Aluminum Flaring Tool (TFA455WH).
Water pump
pliers

Super pilers,
threaded
rod cutters

N.W.
Item No. Number of holes Tube applicable diameter (size name) Plumbing
（g） tool set
TFAG455N 5 1/4 ・ 3/8 ・ 1/2 ・ 5/8 ・ 3/4 190

●For all the appendix of the piping tools, please refer to P.283 91
