MFTN68A

■ VERTICAL MOTOR WRENCH,
Aluminum Alloy Body

Features
● The aluminum alloy body prevents damage on sanitary
pipe nut.
● With wide jaw opening and compact and light-
weighted body, optimal for use in confined space.
Example
of use
PIPING TOOLS
Avoid tightening work
exceeding 100N·m torque.

Size （mm） N.W.
Item No.
Jaw width Jaw depth Jaw thickness Full length （g）
MFTN68A 16〜68 60 9.5 205 210

Tube
cutters
MFTR68A ・ A68A

Other
cutters ■ VERTICAL MOTOR WRENCH,
Aluminum Alloy Body, Ratchet Type

Pipe scrapers,
super torque Features
wrenches
● The aluminum alloy body prevents damage on sanitary
pipe nut.
● With wide jaw opening and compact and light-
Flaring tools
weighted body, optimal for use in confined space.
Example
■ Attachment (a pair) of use
Flanging
tools for Item No.
flexible tube
A68A
attachment Avoid tightening work
(for nut holding) exceeding 100N·m torque.
■ Wide type with ratchet mechanism
Benders Size （mm） N.W.
Item No.
Jaw width Jaw depth Jaw thickness Full length （g）
MFTR68A 16〜68 60 9.5 210 250
＊ Mouth width when attachment (A68A) is put on : 12〜64mm.
Chain pipe
wrenches ૣૹΓػߏ ɿ ΢ΥʔϜΛԼʹҾ͘͜ͱͰ
ૉૣ͘ޱ։͖Λௐ੔Ͱ͖Δ
Pipe
wrenches, MWS
belt L
wrenches
■ SUPER WIDE ADJUSTABLE ANGLE
Motor WRENCH (Quick Adjusting Type)
wrenches,
other
wrenches
MWS200
Jaw Features
opening
● Quick worm slide, super wide jaw opening, light-
Water pump weighted thin type.
pliers
# ● The quick worm sliding mechanism allows very fast
ޱ։͖
size adjustment.
5
5 T T1 5 T2 ● The push spring worm mechanism avoids looseness.
Super pilers, ʢNNʣ
threaded ● The grip part is designed to be firmly grasped easily.
rod cutters ޱ։͖ #
Size name Size（mm） N.W. Guaranteed
Item No. 5 5 5
（mm） Jaw opening L T ʢNNʣ T1 T2 （g） load （N･m）
Plumbing MWS200 200 0〜38 210 13.5 6.7 10.5 270 294.2
tool set
MWS250 250 0〜50 260 16 7.5 12 480 480.5
MWS300 300 0〜60 320 18.5 8.3 13 810 882.6
100 ●For all the appendix of the piping tools, please refer to P.283
