MGC

■ MAGNETIC SLUDGE STRAINER

T
Features
T1
● To set the device, just sink it into the water or oil tank.
● The pinnate-shaped magnets allow to catch more chips or sludge.
● The caught chips or sludge can be easily removed just by taking off
L the cover.
MGC100 wing bolt H
(material : copper) ● Even with the strong magnets, the cover can be easily taken off just
by pulling the top and bottom rings.
■ Set inside oil tank example
How to use
floating feed discharge cover
sludge (material : PVC) ● Set the top and bottom rings and the
catching base 2 wing bolts.
(material :
bakelite) ● Sink the device into the oil tank. It is
efficient to set it at the entrance of
MAGNETIC SEPARATION
the filter or in a place where the oil
sunken
sludge flow quantity is high.
Applications oil tank catching ● On a regular basis take out of oil
movable tank, loosen the 2 wing bolts, pull
bottom ring top ring
● Purification and cleaning of water or oil tank at hydraulic units or (material : (material : the top and movable down rings and
stainless steel) stainless steel) remove the caught sludge.
machines (wire cut electric discharge device, machining, etc.)
Magnetic flux Environment Size （mm） N.W.
Item No. Magnet type Base color
density temperature L H T T1 （g）
MGC100 Ferrite 0.12T（1,200G） ≦80℃ 110 110 42 20 530 Black
Magnets MGC300 Neodymium 0.35T（3,500G） ≦80℃ 110 110 42 20 680 Brown
MGB556
■ MAGNETIC PEN BAR
Magnetic
sludge
strainers,
magnetic Features
bars,
magnetic ● Telescopic pencil type.
pen bars
● The main body in stainless steel is rust-resistant.
● Ultra-light-weight and strong attraction force.
● Plastic case as standard acc.
Applications
● Removal of chips, abrasive powder, fallen matters from narrow
spots.
● Ideal in machine assembling and processing factories.
Item No. Magnet type Magnetic flux density Environment temperature Attraction force（N） N.W.（ｇ）
MGB556 Neodymium 0.35T（3,500G） ≦80℃ 1.5 27
MGB-S

■ MAGNETIC BAR

Features
● Strong magnet enabling outstanding attraction force.
● The stick shape is ideal to remove iron scrap or sludge from under
MGB600S a machine or from out of reach narrow spots.
● To dispose of the caught matters, just a single action (pulling the
slide handle) is required.
Applications
MGB900S
● Removal of iron scrap or sludge from narrow spots such as
machining tool table slots or vise gaps.
● Removal of iron scrap or sludge from water or oil tank.
Example
MGB1200S
of use
dust stopper slide handle

L2 L1
L

Magnetic flux Environment Attraction Main body Size （mm） N.W.
Item No. Magnet type
density temperature force （N） material L L1 L2 D （g）
MGB600S 650 500 110 32 800
0.35T Stainless
MGB900S Neodymium ≦80℃ 170 950 800 110 32 1,045
（3,500G） steel
MGB1200S 1,200 1,040 160 32 1,220
