FGB

■ UNI-CLAMP (Duck Shaped Type)

Feature
● Convenient usage with screw support plane type or
screw type at the screw hole on the rear part.
FGB20
● Material : S55C
● Heat treatment : Quenched 38～43HRC
H ● Finish : Nickel plating
T
Example of use
C

B1 D B
JIGS AND CLAMPING TOOLS
Screw support
L1
The screw hole at the back
L of the duck shaped main body
can receive a screw support
as shown on the photo.

Size （ｍｍ） N.W.
Jig blocks Item No. Applicable bolt （kg）
L L1 H Screw dia. D T B B1 C
FGB12 125 63 32 M12 17 36 13 10.5 M12 0.38
FGB16 160 80 40 M16 21 48 17 13.5 M14・M16 0.88
FGB20 200 100 50 M20 26 59 21 17.0 M18・M20 1.65
Sub tables FGB24 250 125 63 M24 33 70 26 21.5 M22・M24 2.9
FUB-B

■ UNI-CLAMP (U Shaped Type)
Jig plates
Feature
FUB20B
L
Angle plates ● Convenient usage with screw support at the rear part.
T ● Material : S55C
● Heat treatment : Quenched 38～43HRC
● Finish : Black finish
Setting
blocks B1 B
L1
Precision Size （ｍｍ）
vises Item No. Applicable bolt N.W.
L L1 T B B1 （kg）
FUB12B 100 87 20 40 13 M12 0.37
FUB16B 150 134 23 50 17 M16 0.75
Vacuum FUB20B 200 181 27 60 21 M20 1.41
chucks
FUB24B 250 228 32 70 26 M24 2.35
UC4

Clamp kits
■ U-CLAMP (a Pair)

Screw Feature
supports
● Convenient usage with screw support at the rear part.
● Material : S55C
F ● Heat treatment : Quenched 38～43HRC
Mini blocks,
mini ● Finish : Black finish
supports
G H B
D E
Clamping
tools C
A
Size （ｍｍ） N.W. （kg）
Clamps Item No. Applicable bolt
A B C D E F G H （a pair）
UC4 19 45 114 14 100 77.5 φ14 17 M14・M16 0.78
