PTC-S ・ PSC-S ・ BLC-S

■ LIFTING CLAMP BALANCE SET FOR
PANEL / WOODEN BEAM

Feature
● Set of 2 lifting clamps and 1 applicable balance.
Lifting clamp for Set item Set details
housing panel No. Lifting clamp (2 pcs) Balance (1pc) LIFTING CLAMPS FOR HOUSING
Formwork / panel lifting PTC100S PTC100 PSB508
Panel / beam lifting PTC150S PTC150 PSB508
2 × 4 panel lifting PTC200S PTC200 PSB508
Panel / beam lifting PTC250S PTC250 PSB610
Panel lifting PSC100S PSC100 PSB508
Wooden beam lifting BLC200S BLC200 PSB508

PSB
H2
■ 2-POINT LIFTING BALANCE
T
Lifting
clamps for
Feature formwork /
H panel
● Balance dedicated for safe and well-balanced lifting
H1 operations.
Accessories Lifting
clamps for
● Sling belts panel / beam,
PSB508 L ● Shackles lifting
clamps
dedicated for
Rated Size（mm） N.W. wooden beam
Item No. Applicable lifting clamp for panel
capacity （kg） L H H1 H2 T （kg）
PSB508 500 800 2000 1000 800 □40×□20 5.2 PSC100・PTC100・150・200・BLC200
PSB610 600 1000 1960 1000 800 □40×□20 6 Balance sets,
PTC・PSC・BLC・PAC balances,
PSB620 600 2000 2500 1000 1600 □50×□30 7.2 panel pullers
PSBSL

Lifting
■ SLING BELT FOR BALANCE clamps for
ALC panel,
(a Pair) clamps for
lifting
extruded
cement panel
Feature
● Long swing belts common for all balance sizes.
PSBSL150
Item No. Belt full length（m） Belt width（ｍｍ）
PSBSL150 1.5 25
PSBSL200 2 25
PTP200

■ PANEL PULLER (Panel Pulling Tool)
L

L1 Feature
H
H1 ● Must-have tool for construction method with 2 × 4 panels.
■ Applications Example of use
How to use ■ Setting ■ Pulling together ●Pulling together 2 panels.
● Adjusting outside panels with ink marking.
● Pulling and connecting joint parts of floor
and ceiling panels.
●Pulling together 2 beams.
● Pulling together and assembling wooden
formwork panels.
Size（mm) N.W.
Item No.
Pulling stroke L L1 H H1 （g）
PTP200 30 212 250 80 60 760

★The product parts list and operation manual can be downloaded from our website. 153
