SLH3A
D

■ SUPER LOCK HOOK (Open / Close Lock Type)
D1
Design
preventing Features
finger
pinch. ● During lifting, the close lock is automatically set so
that the load can be lifted safely without coming off.
● When removing the hook, as a lever enables to set an
open lock, removing the hook from works like a crane
H
for instance is very easy.
● The hook mouth opens widely, making load set or
remove operation very simple.
Turning the shackle and ■ Open lock mechanism
close the mouth will lock
the hook automatically. 1) Take down 2) Push down the lever, turn 3) The open lock 4) Just by lifting it, the hook
the load. the lever until the end gets set and the comes off automatically.
and release the lever. shackle stays open. (Be careful of the hook
When lifting in this swing at the
LIFTING CLAMPS FOR STEEL
moment it
position, the shackle comes off.)
turns only to the
L closing direction.
State with the
open lock set.
Vertical & Rated Size （mm） N.W.
lateral Item No. capacity （ton） （kg）
lifting clamps L L1 L2 H H1 H2 D D1 T T1 T2
SLH3A 3 169 78 38 383 280 145 64 32 54 33 18 3.8
SLH-N
Vertical D T2 T Example of use
lifting clamps
■ Laying and removing ■ SUPER LOCK HOOK
D1
road plates
Lateral Features
lifting clamps
● Ideal for laying or removing road plates and for lifting
T1 wire ropes and sling belts.
● The hook mouth opens widely, making load set or
Horizontal H ■ As a safety
lateral remove operation very simple.
lifting clamps, hook for ● During lifting, the close lock is automatically set so
lifting hooks
direct lifting
that the load can be lifted safely without coming off.
■ Operation instructions for lifting a road plate 9〜32
Steel beam over 20 under 60
lifting clamps 1) 2) 3)
When lifting the road When lifting
plate, the shackle further, the
closes automatically. shackle gets over 60
closed and
the close lock
L gets set. over 60
Screw The applicable road plate
cam clamps Set the shackle in the open state and thickness and hole dimensions
SLH2N insert the hook end into the road plate hole. shall be within the ranges of
the drawing and the chart.
Rated Size （mm） N.W.
Beam Item No.
clamps, capacity （ton） H H1 H2 H3 L L1 L2 L3 D D1 T T1 T2 （kg）
safety belt
clamps SLH1N 1 298 210 80 28 140 80 65 32 56 24 48 28 16 2.5
SLH2N 2 336 236 89 30 166 105 75 38 64 32 54 29 18 3.2
SLH3N 3 339 236 89 33 169 105 78 38 64 32 54 31 18 3.4
Super foot
locks,
lifting hooks L2
Example of use SLH-S
■ Laying and removing
H4 road plates ■ SUPER LOCK HOOK
Super lock SLH3S
hooks (with Swivel)
Feature
Drum lift
clamps ● The swivel eye included enables
H smooth returning of wire rope,
■ As a safety
hook for thereby preventing the road
Lifting hooks direct lifting plate from turning.
for forklift,
rail clamps
Rated Size （mm） N.W.
Item No.
capacity （ton） H H1 H2 H3 H4 H5 L L1 L2 L3 T T1 T2 T3 （kg）
Reinforcing
rod vertical SLH2S 2 402 30 166 75 29 4.2
lifting clamps 147 117 70 50 47 38 54 46 19
L SLH3S 3 405 33 169 78 31 4.5
★The product parts list and operation manual can be downloaded from our website.
134 ●For all the appendix, please refer to P.284〜286
