ZEUS WITH INTELLIGENT DIAGNOSTICS

EEMS342EUR DIAGNOSTICS

ZEUS Diagnostic and Information System
®
®
EEMS342EUR ZEUS Intelligent Diagnostic and Information System
• Exclusively hosts the all-new Intelligent Diagnostics* • Factory-installed antivirus and security essentials
• Intelligent Diagnostics provides direct access to key • Comprehensive data manager can store thousands of
information for the specific vehicle and code the vehicle records, customer data, vehicle IDs, fault codes,
technician is handling repair notes and diagnostic results
• Get direct access through Intelligent Diagnostics • Capacitive touchscreen is sensitive to every gesture
to vehicle and code-specific TSBs, smart data, f • Stay connected to the vehicle and the internet while
unctional tests and reset procedures, Fast-Track moving freely around the service bay
®
Troubleshooter Guided Component Test Meter and • Modular, dockable scope/meter with 9ʹ USB cable for
SureTrack information extended reach and portability
®
• TSBs provide the latest information and technical • One-Touch Full Vehicle Code Scan and Clear—quickly
bulletins, straight from the manufacturers checks and clears codes for all available modules
• Smart data automatically creates a custom data list on the vehicle
for a specific code and highlights the values that • Industry-leading functions, tests and coverage
are out of range previously found only in expensive factory tools
• Fast, easy access to expert Information via SureTrack — • OEM-specific coverage for 49 makes, as far back as 1980
®
provides real-world repairs, tips and time savers from (European optional)
real technicians • Codes, live data, functional tests, relearns and
• Avoid unnecessary parts replacement—exclusive Fast- adaptations for hundreds of vehicle systems
Track Troubleshooter Guided Component Tests show • High-speed 4-channel lab/ignition scope and digital/
®
what to test, how to connect and what results to look for graphing meter
®
®
• Access to the optional ShopKey Pro (SureTrack • Six megasamples/second sample rate and glitch-capture
requires Wi-Fi access and the current software upgrade) detects faults that other scopes miss
• Startup in about a minute; powers up in Ready Mode in • Scale range: 0–100 mV to 0–400 V, 50 kV
just five seconds secondary ignition
®
• Secure 64 GB solid-state drive and a Quad-core Intel • Sweep rate: 50 microseconds to 20 seconds (5 min in
Celeron processor (1.83 GHz, 2 GB RAM, 32-bit) GMM mode) so the technician doesn’t miss a thing
®
• Built-in Wi-Fi and internet browser for the freedom to • Exclusive Fast-Track Guided Component Tests for
®
work wirelessly 40 domestic, Asian and European makes
• Thin, light tablet-style design with a high-resolution • V DC, V AC, ohms, frequency, duty cycle, pulse width,
1,280 x 800 pixel display diode test and more
*For full functionality a subscription or current software license must be in place.
ZEUS Accessories
®
EAX0068L27A OBD-I DA-6 Cable Adaptor
• Expands the capabilities of the Compact Scan Module to include domestic,
Asian, and European vehicles that use OBD-I test connections
EAX0072L01A DA-4EX OBD Cable Extender EAX0068L27A
• Expands the use of the SCAN Module Compact Scan Module in tight areas under
the dash
EAX0072L01A
877
• Do not use in atmosphere with explosive vapor
• Read safety precautions on pages W1 to W4
