PLASMA CUTTERS

PLASMA20i WELDING
PLASMA30i PLASMA60i

Inverter-style Plasma Cutters
• Depth-of-cut adjustability—for applications such as panel removal around spot
welds—adjusts cut-depth to the top layer of material without disturbing the base layer
Specifications PLASMA20i PLASMA30i PLASMA60i
Output Current, amps 5–20 5–25 20–55
Cut Thickness, inches 1/4 3/8 3/4
Sever Thickness, inches 3/8 1/2 1
Primary Input, volts 115 V AC, 50/60 Hz 115 or 230 V AC, 50/60 Hz 208/230 V AC, 50/60 Hz
Primary Input, amps 20 30 A 115 V or 20 A 230 V 40 A
Duty Cycle Rating 100% @ 15 A 100% @ 19 A 100% @ 30 A
Compressed Air Requirements (min) 50 PSI @ 5 CFM 50 PSI @ 7 CFM 68 PSI @ 7 CFM
Torch Cable Length, feet 12 12 18
Ground Cable Length, feet 12 12 18
Net Weight, lb (kg) 22 (10) 29 (13) 44 (20)
PLASMA20i 20 A Plasma Arc Cutting Machine PLASMA30i Plasma Cutter
• Perfect for the shop or on the jobsite, it features a small- • Inverter technology features a small-yet-powerful
yet-powerful package size that allows for portability in a package size that allows for portability in a variety of
variety of situations situations in the shop or on the jobsite
• Ideal for cutting a variety of ferrous, non-ferrous and • Cuts a maximum of 3/8ʺ and will sever up to 1/2ʺ
high-strength materials • Adjustable amperage range—from 5–25 A—provides the
• Cuts a maximum of 1/4ʺ and will sever up to 3/8ʺ ability to minimize distortion on thinner materials
• Adjustable amperage range—from 5–20 A—provides the • Material capability ideal for cutting a variety of ferrous,
ability to minimize distortion on thinner materials non-ferrous and high-strength material
• Accepts 115 V input power supply voltage at minimum • Pilot self-restart function provides the ability to cut
current requirements perforated, grid or expanded metal applications
• Contains an air filter and pressure regulator to allow for • Air supply system contains an air filter and pressure
either a compressed air or nitrogen air supply regulator to allow for either a compressed air or nitrogen
• Technical support and service: 800-ABC-WELD air supply
• Protection LED warning system for low air pressure, high
temperatures and system blockages
• Input voltage versatility automatically accepts 115 or
230 V input power supply voltages at minimum
current requirements
• Ideal for automotive repair, collision repair, heavy-duty
truck, farm and metal fabrication shops
• Comes complete with a power supply, torch assembly,
ground cable and spare torch consumables
PLASMA60i Plasma Cutter
• Cutting capacity cuts a maximum of 3/4ʺ and
severs up to 1ʺ
• Input voltage versatility accepts 208 V or 230 V input
power supply voltages at minimum current requirements

659
• Wear face shield and protective clothing while welding and cutting
• Do not allow bystanders while welding and cutting
• Read safety precautions on pages W1 to W4
